ABB DO880 3BSE028602R1 – 16-Channel 24V DC Digital Output Module
Product Overview
The ABB DO880 3BSE028602R1 is a 16-channel 24V DC digital output module designed for single or redundant industrial automation applications. It solves the core challenge of reliably driving field devices like relays, solenoid valves, and indicators while ensuring operational safety in critical control systems. Integrating seamlessly with ABB’s 800xA, S800, and Advant Controller 400 platforms, this module delivers stable current-sourcing output, with built-in protection to prevent failures from short circuits and overheating—common issues in harsh industrial environments. Its compact design and versatile compatibility make it ideal for power, manufacturing, and marine automation setups.
Technical Specifications — DO880 3BSE028602R1
| Parameter | Value |
|---|---|
| Product Model | DO880 3BSE028602R1 |
| Manufacturer | ABB |
| Product Type | 16-Channel 24V DC Digital Output Module |
| Power | 24V DC (19.2-32V DC), 5.6W power dissipation |
| Communication / Protocol | Modulebus, Modbus RTU |
| Operating Temperature | -40°C to +70°C |
| Mounting | DIN-rail modular mounting |
| Dimensions (HxWxD) | 112mm × 90mm × 103mm |
| Weight | Approximately 0.3kg |
| Typical Interfaces | Modulebus, 16 digital output channels, status LED indicators |
| Compliance | IEC 61508 SIL3, EN 954-1 Category 4, CE marked |
ABB DO880 3BSE028602R1
Key Features and Benefits — DO880 3BSE028602R1
- 16 independent channels with 0.5A max continuous output current per channel, supporting current limiting to prevent short-circuit damage.
- Built-in over-temperature protection and EMC components, reducing interference and ensuring long-term reliability in harsh industrial settings.
- Loop monitoring function with configurable limits, enabling supervision of short and open loads without pulsing outputs.
- Supports both single and redundant configurations, adapting to critical control systems where downtime is costly.
- Groupwise isolation from ground and module bus isolation barrier, minimizing signal interference and enhancing operational safety.
Related Models
- ABB DO810 3BSE008510R1: 8-channel digital output module, ideal for smaller-scale automation setups requiring fewer output channels.
- ABB DO820 3BSE013269R1: 16-channel digital output module with enhanced diagnostic capabilities for complex industrial systems.
- ABB DI880 3BSE028601R1: 16-channel digital input module, complementary to the DO880 for complete I/O control in ABB platforms.
- ABB DO881 3BSE028603R1: High-integrity 16-channel digital output module with extended fault tolerance for safety-critical applications.
Installation and Maintenance — DO880 3BSE028602R1
Mount the module on a standard DIN-rail for easy integration into control panels. Connect field devices to the 16 output channels, ensuring proper wiring to avoid short circuits. Routine maintenance involves checking status LEDs for error indicators and inspecting connections for dust buildup or loosening. Avoid exposure to corrosive substances and ensure operating temperature stays within the specified range to preserve performance.
Product Warranty — DO880 3BSE028602R1
The module comes with ABB’s standard industrial component warranty, covering manufacturing defects for 12 months from the purchase date. Warranty does not apply to damage from improper installation, misuse, or operation outside specified parameters. Proof of purchase is required for warranty claims, and ABB provides technical support for installation and troubleshooting.
Personally, I found that the DO880 3BSE028602R1’s loop monitoring feature is incredibly useful for catching load issues early, which saves time on troubleshooting in busy industrial plants. Its compatibility with multiple ABB platforms also makes it a versatile choice—no need to reconfigure existing systems when adding or replacing modules.
