Description
Technical Specifications
| Product Model | **SST-PB3-PCU V1.7.2 PB3-PCI** |
| Manufacturer | SST |
| Product Type | Profibus PCI Communication Card |
| Interface | PCI 2.2 Compliant |
| Data Transfer Rate | Up to 12 Mbps |
| Protocol Support | Profibus DP/V0 |
| Isolation Voltage | 1500 VDC |
| Operating Voltage | +3.3V/+5V (PCI Bus Powered) |
| Operating Temperature | 0°C to +60°C |
| Certifications | CE, FCC, RoHS |
| Compatibility | Windows 10/11, Linux 4.x+ |
| Dimensions | 120 x 20 mm |
Key Features and Advantages
The **SST-PB3-PCU V1.7.2 PB3-PCI** enables seamless integration of Profibus networks with PC-based control systems, featuring automatic baud rate detection and real-time data processing. Its galvanic isolation protects host systems from electrical noise in industrial environments, while the dual-port design allows daisy-chaining of multiple devices without external repeaters. The card’s advanced diagnostics include cable fault detection and slave status monitoring via onboard LEDs.
Optimized for reliability, the hardened PCB coating resists humidity and chemical exposure. The low-profile bracket accommodates compact industrial PCs, and the 32-bit DMA architecture ensures minimal CPU load during high-speed data exchange. Preconfigured GSD files simplify integration with leading PLC platforms like Siemens STEP 7 and TIA Portal.
SST-PB3-PCU
Application Areas
In automotive assembly lines, the **SST-PB3-PCU V1.7.2 PB3-PCI** connects robotic welding controllers to centralized SCADA systems. Water treatment plants utilize its robust communication for distributed I/O monitoring across pump stations. The card’s deterministic response time supports real-time quality control in pharmaceutical packaging machinery, while its Linux compatibility enables integration with custom MES solutions in discrete manufacturing.
Related Products
**SST-PB3-USB**: Portable Profibus USB adapter.
**SST-PN3-PCI**: Profinet PCIe communication card.
**PB-OLM**: Optical link module for long-distance networks.
**SST-EDS**: Configuration software suite.
**PB-FC**: FastConnect cabling system optimized for **SST-PB3-PCU** installations.
Installation and Maintenance
Installation preparation: Verify PCI slot compatibility and disable onboard COM ports conflicting with Profibus addresses. Install heatsink thermal pads if operating in sustained >50°C environments. Use impedance-matched Profibus connectors and terminators for signal integrity.
Maintenance recommendations: Update firmware biannually using SST Flash Tool. Clean gold contacts annually with isopropyl alcohol. Monitor driver-level diagnostics for early detection of network packet errors. Replace after 7 years of continuous operation in high-vibration settings.
Product Assurance
SST’s **SST-PB3-PCU V1.7.2 PB3-PCI** undergoes 1,000-hour MTBF testing under full load conditions. The 5-year warranty covers manufacturing defects, with lifetime technical support for protocol stack integration. Compliance with IEC 61158-2 ensures interoperability in mixed-vendor Profibus networks, while ESD protection up to 15kV safeguards against static discharge events.
