Description
FloBoss S600+ (Model FSFBS600+/S600P1-0-B-0-0-1) panel mounted flow computer
Product Description
The FloBoss S600+ (Model FSFBS600+/S600P1-0-B-0-0-1) is a panel mounted flow computer from Emerson designed for hydrocarbon liquids and gases measurement with high versatility and accuracy. Here are some of the key features and parameters of the product:
Application areas: Financial flow measurement, custody transfer, pipeline measurement, batch loading, instrument validation applications, single or multi-flow measurement, flow control, etc.
Supported flow meters: Turbine, ultrasonic, Coriolis, positive displacement, orifice, Venturi, Annubar, V-Cone® and Rosemount adjustable orifice plates are supported.
Global Measurement standards: Support for a wide range of global measurement standards including AGA, ISO, GPA, GERG and GOST (gas applications) as well as API, ASTM, GPA and NORSOK (liquid applications).
Processing power: It adopts distributed processing, has a more powerful main processor than the previous S600, and has a built-in hardware floating-point processor to perform faster calculations, minimize uncertainty, and maximize control.
FLOBOSS S600
Product parameter
Data Logging and archiving: Significantly enhanced data logging and archiving capabilities, including extended history. A typical archive includes 333 days of monthly, weekly, daily, and hourly reports, and 50,000 events and alerts.
User interface: Equipped with 8-line LCD display and 29-key keyboard, supports English and Russian character sets, and can view or modify system parameters without PC.
Communication options: Flexible communication options, including Ethernet, serial, and HART ports, support multiple device connections.
Analog input: High precision analog input 24 bits, full scale accuracy at 23℃ is ±0.005%.
Ambient temperature range: -10℃ to +60℃.
Power supply: 20 to 32Vdc power supply, typical power consumption of 18W (1 I/O module configuration).
Physical characteristics: IP50 front panel protection class, weighing about 4.3kg (single I/O module configuration).
Compatibility: Fully backward compatible with the S600 model, using existing configurations and tools to protect the user’s capital investment in the S600.
Certification: Intermediate certification for liquid and gas applications, reducing risk and ensuring compliance with the highest financial requirements.
The FloBoss S600+ traffic computer is Emerson’s market-leading product, taking all the features of its predecessor, the S600, and improving and enhancing it to make it more suitable for high-precision applications such as trade metering. It supports multi-flow (up to ten optional expansion modules), multi-station (up to two) applications, and can simultaneously measure natural gas, wet gas, crude oil, refined oil, liquefied petroleum gas, natural gas liquids, and more. The S600+ can also accommodate both liquid and gas stations, providing unprecedented support for global measurement standards.
Application field
The FloBoss S600+ flow computer supports a variety of global measurement standards including AGA, ISO, GPA, GERG, GOST (gas applications) as well as API, ASTM (liquid applications). It uses distributed processing technology with a more powerful main processor built in than the original S600, and the new CPU contains a hardware floating-point processor that provides faster computing power, minimizes uncertainty and maximizes control. Data logging and archiving capabilities have been significantly improved, including an extended history feature capable of storing up to 333 days of monthly, weekly, daily, and hourly reports, as well as up to 50,000 events and alerts. The user interface features an eight-line LCD display and a 29-key keyboard, supports both English and Russian character sets, and allows you to view or modify system parameters without a PC. The S600+ is fully backward compatible with the S600 model, taking advantage of the existing configurations and tools you are familiar with, and saving you the time to learn the configuration of new tools.
With its advanced technology, powerful functions and flexible configuration, the FloBoss S600+ flow computer provides a reliable flow measurement solution for customers in the energy and transportation sectors.
