Description
F650-N-F-L-F-2-G-1-HI-P-6E high-end feeder protection and bay area controller
Product Description
The F650-N-F-L-F-2-G-1-HI-P-6E is a high-end feeder protection and bay area controller in the GE Multilin family, part of the GE F650 family. This device adds more functions and features to the F650 series to meet the needs of more complex power system protection and control. Here are some of the key features and parameters of the product:
Protection function: Provides overcurrent, ground fault, voltage loss, overvoltage, negative sequence current, harmonic overcurrent, transient overvoltage and other protection functions.
Communication interface: Support RS232, RS485, Ethernet, IEC 61850 and other communication protocols, can be easily integrated into the SCADA system, and support the interconnection with other smart devices.
Display: With a large color touch screen, it provides an intuitive user interface.
Storage capacity: It can store a large number of event records and curve data for fault analysis and system monitoring.
Ambient temperature: suitable for -25℃~+70℃ working environment.
Applications: Widely used in power systems, industrial enterprises, public facilities, new energy and other fields, especially in the need for highly reliable and accurate motor protection, such as power plants, substations, large industrial production lines.
In addition, the F650-N-F-L-F-2-G-1-HI-P-6E also features advanced automation functions such as self-healing, load transfer, and an enhanced human-machine interface to provide a more intuitive and user-friendly operation experience. It also supports the access and control of distributed energy sources and realizes the intelligence of the power grid.
F650-B-F-G-F-1-G-1-HI-E
Product parameter
Protection function: Offers include time, instantaneous and directional phase, neutral, ground and sensitive ground overcurrent protection, second harmonic suppression, CT monitoring, manual closing control, forward and directional power units, load encroachments monitoring, watt-metering ground fault detection, positive and negative sequence based overvoltage/undervoltage elements, four automatic reclossing with synchronous check, trip loop monitoring, and more. Circuit breaker control and circuit breaker failure, frequency protection (rate of change and six frequency too low and too high protection), broken line and locked rotor detection.
Control functions: feeder switch control, isolation switch control, reactive power compensation control, power flow control, etc.
Communication interface: Support a variety of communication protocols, such as RS232, RS485, Ethernet, IEC 61850, etc., easy to integrate with SCADA systems and other smart devices.
Display: With a large color touch screen, it provides an intuitive user interface.
Storage capacity: It can store a large number of event records and curve data for fault analysis and system monitoring.
Ambient temperature: Suitable for -25℃ to +70℃ working environment.
Size and weight: Size is about 482mm x 269mm x 222mm, weight is about 15kg.
Applications: Widely used in power systems, industrial enterprises, public facilities, new energy power generation systems, especially in the need for highly reliable and accurate motor protection, such as power plants, substations, large industrial production lines, etc.
Key benefits: Comprehensive and flexible protection and control equipment, increased system uptime, improved stability, load reduction and transfer solutions, advanced automation features, simplified integration of systems and communications.
Series: Part of the GE Multilin F650 series, a series designed for motor protection and control.
Application field
Power systems: used for feeder protection and automation in distribution and transmission networks to ensure the safe operation and reliability of the grid.
Power plants: Protect generators, transformers and other critical equipment from failures such as short circuits, overloads and overvoltages.
Substation: Protection and control of feeders and transformers as part of substation automation system.
Industrial enterprise: In an industrial environment, the power systems used to protect and control the plant, including production lines, mechanical drive systems, etc.
Commercial buildings: In the power system of commercial buildings such as shopping centers, office buildings, etc., used to ensure the stability and safety of power supply.
Public facilities: Ensure the safety and reliability of critical power systems in the power systems of public places such as hospitals, schools and airports.
New energy system: In photovoltaic, wind power and other new energy power generation systems, used to protect and control power generation equipment, as well as to achieve interconnection with the grid.
Distributed energy management: In a distributed energy system, it is used to protect and control distributed power generation resources, such as solar photovoltaic panels, wind turbines, etc.
Automatic control systems: provide precise control and protection in situations that require automatic control, such as automated production lines, intelligent building management systems, etc.
Fault diagnosis and system monitoring: In the system requiring real-time monitoring and fault diagnosis, it is used to monitor the operating status of the power system in real time, and quickly diagnose and respond to system faults.
