Description
Ordering & Delivery Assurance
Each HIMA X-A13201 unit carries a 12-month warranty from date of receipt. In-stock items ship within 1 week; sourcing orders require a maximum of 4 weeks. Payment terms are 50% advance with balance due before dispatch, and all shipments are sent via FedEx, UPS, or DHL express courier.
Key Practical Features
Technical Specifications
| Power Requirements | 24 VDC supplied via HIMAX backplane; typical consumption < 2 W per channel group |
| Dimensions & Mounting | 230 mm × 30 mm × 170 mm (L × W × H); plug-in card format for HIMAX base rack slot |
| Operating Temperature | 0 °C to +60 °C (standard industrial range per HIMA HIMAX platform specification) |
| Signal I/O Types | 4–20 mA analog input/output; galvanically isolated channels; supports 2-wire and 4-wire transmitter connections |
| Communication Interfaces | Internal HIMAX backplane bus to safety processor; no external fieldbus on this sub-module |
| Installation Method | Hot-pluggable into designated HIMAX base rack slot; secured by rack guide rails and locking mechanism |
Compatible & Supporting Modules
HIMA F3236 – 16-channel digital input module for HIMAX base racks, providing 24 VDC dry/wet contact acquisition with channel-level diagnostics. It occupies the same rack form factor as the X-A13201 and shares the backplane communication path.
HIMA F3330 – 8-channel digital output module with relay contacts rated for safety shutdown actuation. In standard configurations it pairs with analog input boards like the X-A13201 to form a complete cause-and-effect loop.
HIMA F6217 – 24 VDC power supply unit supporting redundant (1oo2) configuration for HIMAX racks. One thing to note is that adequate power budgeting is required when multiple analog sub-modules such as the X-A13201 are populated in a single rack.
Field Installation & Routine Maintenance
The HIMA X-A13201 is designed for insertion into a HIMAX base rack mounted on standard 19-inch or DIN-rail cabinet frames; ventilation clearance of at least 50 mm above and below the rack should be maintained per HIMA installation guidelines. Terminal wiring for 4–20 mA loops should use shielded twisted-pair cable with the shield grounded at the cabinet entry point only.
Firmware and configuration data should be backed up via the HIMAX engineering station before any module replacement. Calibration verification is typically recommended at 12-month intervals using a certified loop calibrator, following the manufacturer’s maintenance schedule.
Compliance & Quality Backing
The HIMA X-A13201 is manufactured in Germany and conforms to CE marking requirements, IEC 61508 SIL3 safety integrity, and RoHS substance restrictions as part of the HIMAX platform certification scope. Each unit is covered by a 12-month warranty, with delivery within 1 week for in-stock items or up to 4 weeks for sourced units, under 50% advance payment terms with balance before dispatch.
Please contact Sunny sales@xiongbagk.cn for the best price.
