Description
Ordering & Delivery Assurance
Each HIMA X-COM 01 unit carries a 12-month warranty from date of delivery. In-stock items typically ship within 1 week; sourcing orders require a maximum of 4 weeks. Payment terms are 50% advance with balance due before dispatch, and express shipping via FedEx, UPS, or DHL is available worldwide.
Key Practical Features
Technical Specifications
| Power Requirements | 24 VDC nominal (supplied via HIMAX rack backplane); typical consumption < 5 W |
| Dimensions & Mounting | 255 mm × 30 mm × 170 mm (H × W × D); single-slot insertion in HIMA HIMAX 19-inch rack |
| Operating Temperature | 0 °C to +60 °C (ambient at module position); storage −25 °C to +70 °C |
| Signal I/O Types | 2 × RJ45 Ethernet ports (10/100 Mbit/s); status LEDs for link, activity, and diagnostics |
| Communication Interfaces | Safeethernet, Modbus TCP, Profinet IO, EtherNet/IP; backplane interface to X-COM 01 HIMAX CPU |
| Installation Method | Hot-pluggable module insertion into HIMAX rack slot; front-accessible RJ45 connectors; no tools required for module exchange |
Compatible & Supporting Modules
HIMA X-CPU 01 – The primary HIMAX safety logic processor that the X-COM 01 communicates with via the rack backplane. Available in single and redundant (1oo2D) configurations for SIL 3 applications.
HIMA X-DI 16 – 16-channel digital input module for the HIMAX rack, providing fail-safe signal acquisition from field devices such as pressure switches and flame detectors.
HIMA X-DO 08 – 8-channel digital output module delivering fail-safe actuation signals to final elements including solenoid valves and motor starters within the safety loop.
Field Installation & Routine Maintenance
The HIMA X-COM 01 installs into a standard HIMAX 19-inch rack slot with front-panel RJ45 access; ventilation clearance of at least 50 mm above and below the rack should be maintained per manufacturer guidelines. Terminal wiring is limited to the Ethernet patch cables, and cable routing should avoid proximity to high-voltage power conductors to reduce EMI coupling.
Firmware backup of the communication configuration should be performed before any module replacement, using the HIMA SILworX engineering environment. In standard configurations, no periodic calibration is required; however, a visual inspection of connector integrity and LED status is recommended during each scheduled maintenance window.
Compliance & Quality Backing
The HIMA X-COM 01 is part of the HIMAX platform certified to IEC 61508 SIL 3 and carries CE marking; the manufacturing system operates under ISO 9001 quality management. One thing to note is that RoHS compliance applies to all electronic assemblies produced after 2015. Each unit ships with a 12-month warranty, delivery within 1 week for in-stock items (maximum 4 weeks for sourcing), and payment structured as 50% advance with balance before dispatch.
