FC-IOCHAS-0001R redundant I/O module rack

The Honeywell FC-IOCHAS-0001R is a redundant I/O module rack from Honeywell that is designed to house and power multiple I/O modules while supporting redundant configurations to ensure high reliability in industrial automation and control systems. Here are some of the key features and parameters of the product:

Redundant design: Supports a redundant configuration with two power supplies and backplane connections, ensuring that the system continues to operate even if one power supply or communication path fails.

Modular design: A variety of plug-in I/O modules are accepted, allowing customization to the specific input and output requirements of the control system.

Backplane communication: Provides a backplane for communication between the I/O module and the main control system.

Status indicators: May include LED indicators to show the status of power supplies, modules, and communication links.

Typical applications:

Industrial Automation Systems: Provide a reliable connectivity platform for various sensors and actuators in factory automation or process control applications.
Building automation systems: Can be used to interface with sensors and actuators to control HVAC systems, lighting, and other building functions.
SCADA (Supervisory Control and Data Acquisition) system: acts as the I/O interface to the SCADA system, collecting data from sensors and sending control signals to actuators in a larger facility.
Technical specifications:

Power consumption: 5V-1: 35 mA (IO-0001 slot 20), 5V-2: 35 mA (IO-0001 slot 21).
Dimensions: Approximately 48.3×29.5×23.5 cm.
Installation: Usually installed in a 19-inch cabinet and used together with other I/O modules.

Certification: May include CE, UL, CSA, TUV, FM, etc.

The rack is part of the Honeywell Experion family of control systems that provide a reliable platform for building and scaling industrial automation and control applications.
