Description
Ordering & Delivery Assurance
The AKT 0100-71443 carries a 12-month warranty from date of receipt. In-stock units ship within 1 week; sourced units require a maximum of 4 weeks. Payment terms are 50% advance with the balance due before dispatch, and all shipments are sent via FedEx, UPS, or DHL with full tracking.
Key Practical Features
Technical Specifications
| Power Requirements | DC bus input from system power supply; distributes regulated DC to ozone generator and chamber subsystems |
| Dimensions & Mounting | Approx. 280 mm × 200 mm × 35 mm; card-edge or slot-mounted in equipment rack |
| Operating Temperature | Typically 0 °C to +50 °C (ambient within equipment enclosure) |
| Signal I/O Types | DC power distribution outputs, VMEbus parallel data/address bus, discrete control signals |
| Communication Interfaces | VMEbus (IEEE 1014) backplane interface for inter-module data exchange |
| Installation Method | Inserted into designated card slot within AMAT CVD or AKT display panel tool chassis; secured with retention hardware |
Compatible & Supporting Modules
AKT 0100-09047 – Companion interface card that pairs with the 0100-71443 to provide full VMEbus communication and expanded I/O channel count across the chamber control backplane.
AMAT Centura DC Power Distribution Unit – Supplies regulated DC bus voltage to the 0100-71443 for downstream routing to ozone generators and process chamber heaters. Typically rated for the specific voltage and current envelope of the deposition recipe in use.
AKT VMEbus Backplane Assembly – Provides the IEEE 1014 slot infrastructure into which the 0100-71443 and associated controller cards are inserted. Slot width and pin assignment must match the card-edge connector specification.
Field Installation & Routine Maintenance
The AKT 0100-71443 is installed into a designated card slot within the equipment chassis; verify that the slot keying and retention clips are fully engaged before powering the system. Ventilation clearance around the card should exceed 25 mm on all sides to prevent thermal accumulation, and terminal wiring must follow the pinout diagram in the AMAT service manual.
Routine maintenance involves inspecting card-edge connectors for oxidation and confirming firmware version against the latest AKT release notes. A firmware backup should be captured before any card replacement, and calibration of associated power distribution channels is typically recommended at12-month intervals per manufacturer guidelines.
Compliance & Quality Backing
The AKT 0100-71443 is manufactured under Applied Materials quality systems and carries CE marking; RoHS compliance applies to applicable material subsets. Each unit is backed by a 12-month warranty, with in-stock delivery within 1 week and payment structured as 50% advance, balance before dispatch via FedEx, UPS, or DHL.
