Description
Product details:
- Product No. : P0972ZA
- Model : FCM100E Field Communication Module with Fibre Optic
- Module Fieldbus Communications Transmission rate : 2 Mbps for 200 series DIN FBMs or 268 Kbps for 100 series FBMs
- Ethernet Fieldbus Communications Transmission rate : 100 Mbps
- 2 Mbps Fieldbus cable length : 20 m max
- 2 Mbps Fieldbus 200 Series FBMs : 32 (max) Fieldbus Modules per FCM100E depending on control processor sizing constraints
- 268 Kbps Fieldbus cable length : 1830 m max
- 268 Kbps Fieldbus 100 Series FBMs : 64 (max) Fieldbus modules per FCM100E depending on control processor sizing constraints.
- Input voltage range : 21 to 42 V dc
- Consumption : 5 W (max)
- Operating temperature : 0 to 70°C (32 to +158°F)
- Operating relative humidity : 5 to 95% (noncondensing)
- Operating altitude : –300 to +3,000 m (–1,000 to +10,000 ft)
- Cable material : MMF 62.5/125 um
- Cable lengths : 3m up to 2km, greater than 50m – user supplied
- Dimensions (HxWxD), approx : 11.4cm x 5.15cm x 14.7cm
- Shipping Weight : 3 Kg
Recommended model:
FBM230 4-channel serial communication single card 4 RS232/422/485 ports
FBM231 4-channel serial communication redundant components 4 RS232/422/485 ports
FBM232 10/100MB Ethernet communication single card 1 10/100M RJ45 port
FBM233 10/100MB Ethernet communication redundant single card 1 10/100M RJ45 port
FBM237 redundant 8-channel 0-20MA output interface components optional redundant 8AO
FBM241 8-channel voltage monitoring input, 8-channel discrete output (external power supply) 8DI/8DO
FBM241b 8-channel voltage monitoring input, 8-channel discrete output (internal power supply) 8DI/8DO
FBM241c 8-channel contact input, 8-channel discrete output (external power supply) 8DI/8DO
FBM241d 8-channel contact input, 8-channel discrete output (internal power supply) 8DI/8DO
FBM242 16-channel contact output (external power supply) interface component (optional redundancy) optional redundant 16DO
FBM231 4-channel serial communication redundant components 4 RS232/422/485 ports
FBM232 10/100MB Ethernet communication single card 1 10/100M RJ45 port
FBM233 10/100MB Ethernet communication redundant single card 1 10/100M RJ45 port
FBM237 redundant 8-channel 0-20MA output interface components optional redundant 8AO
FBM241 8-channel voltage monitoring input, 8-channel discrete output (external power supply) 8DI/8DO
FBM241b 8-channel voltage monitoring input, 8-channel discrete output (internal power supply) 8DI/8DO
FBM241c 8-channel contact input, 8-channel discrete output (external power supply) 8DI/8DO
FBM241d 8-channel contact input, 8-channel discrete output (internal power supply) 8DI/8DO
FBM242 16-channel contact output (external power supply) interface component (optional redundancy) optional redundant 16DO
