Description
Product details:
Reliance Electric’s 0-52712-7 is a PC output frequency module card. The board is manufactured by Reliance for use in the company’s drive systems. In some cases, the product may come from Baldor-Reliance or ABB. In all cases, the part id number will remain the same.
The 0-52712-7 does not include a front panel like many cards in the series. Instead, the 0-52712-7 is a pentagonal card with a narrow leading edge designed like a handle. The edge has an oval incision within its boundary. The front left edge of the card is cut off and tilted down to meet the left edge of the card, creating a fifth cardboard edge. This edge has a large black component that serves as the output module of the circuit board. The module, labeled UM50872, is designed as two interlocking pieces. The motherboard also has a separate black component on the back edge, labeled 800756-6A. This uses three screws threaded through the bottom of the card to attach to the plate.
![](http://www.sauldcs.com/wp-content/uploads/2023/04/6de470ece8c2dcbc831b.jpg)
0-52712-7
The motherboard also has a separate black component on the back edge, labeled 800756-6A. This uses three screws threaded through the bottom of the card to attach to the plate.
Other components on the PCB surface include ceramic capacitors, metal film resistors, two types of transistors, diodes, surface wiring connected to vertical pin elements, and 14 integrated circuits. The IC includes a binary counter and an analog bus driver.
