Description
The mainstream servo drivers of SYHNC100-NIB-2X/W-24-P-D-E23-A012 all adopt digital signal processor
(DSP) as the control core, which can realize more complex control algorithm, and realize digitalization, networking
and intellectualization. Power devices generally use intelligent power module (IPM) as the core design of the drive
circuit,IPM internal integrated drive circuit, and has overvoltage, overcurrent, overheating, undervoltage and other
fault detection protection circuit, in the main circuit also added soft start circuit, in order to reduce the impact of the start
process on the driver. SYHNC100-NIB-2X/W-24-P-D-E23-A012 Power drive unit first rectify the input three-phase power
or mains power through the three-phase full-bridge rectifier circuit to obtain the corresponding direct current. The
three-phase permanent magnet synchronous AC servo motor is driven by the three-phase sinusoidal PWM voltage inverter. The
whole process of power drive unit can be simply described as AC-DC-AC process. The main topological circuit of AC-DC is the three – phase full – bridge uncontrolled rectifier circuit.
