The EGCP-3 8406-113 control is a microprocessor-based generator load control designed for use with a separate
speed control and automatic voltage regulator to provide synchronization, shunt, load and unload.
Coordinate all transitions between EGCP-3 functions to provide smooth operation.
EGCP-3 8406-113 Least Squares function:
Display/keyboard interface for local setup/monitoring
Engine start-stop sequence control
Generator and bus power monitoring
Cell sorting and single cell protection
Engine protection and monitoring
Synchronous instruments include speed, phase, voltage matching, token passing dead bus closure, and multiple unit synchronization
KW control and automatic generator loading and unloading without bumpy load transfer
Droop, base load, isochronous and isochronous load sharing control capabilities
Frequency and voltage adjustment in synchronous mode Communication bus between master and other LS units master/slave control cogeneration,
import/export, pressure control, or other processes KVAR/PF control is shared with bus /PF
Single generator stable timing built-in diagnostic generator and busbar protection relay protection generator power and energy metering Modbus·
and SeryLink communication for remote HMV/PLC connection
The EGCP-3 8406-113 has a keyboard and two 4-wire display panels in the front cabinet mounted case.
Displays can be used to configure and set up controls specific to field requirements.
The display is also used for normal operational services to monitor operations and view alarm data.
All functions performed by the front panel and monitored parameters can also be accessed through the three serial ports.
These ports can be configured to use Woodward Watch Window software, external HMI and Modbus communication, or ServLink DDE software.
WOODWARD 5466 Series modules 5466-316, 5466-258, 5466-348, 5466-1035, 5466-253, 5466-258, 5466-355, 5466-258, 5466-409, 5466-315
