Developed based on Tuyang’s enhanced binocular speckle structured light technology platform, the PS800 is a new member of Tuyang’s P series, and constitutes a complete close-range product line with the already mass-produced and popular FS820. Both the PS800 and FS820 are targeted for near-field applications up to 1 meter, with the FS820 optimized for lower cost and the PS800 focused on precision optimization, providing the optimal product options for cost-sensitive applications and high performance needs, respectively.

PS800-E1 product highlights

High precision 3D measurement performance
PS800 myopia field accuracy is XY: 0.5@200mm, Z: ±0.1@200mm; The accuracy of the far-sighting field is XY: 2.35@1000mm, Z: ±2.3@1000mm. Provides the highest precision performance under the speckle structured light technology route.

In addition, the configured narrowband filter and floodlight fill light, combined with image optimization algorithms, can ensure consistent high-quality 3D point cloud image output in the presence of different lighting, reflection, absorption and other interference.

9566-8XX

Smaller blind spots, HD field of view is in control
The PS800’s working distance is 0.2-1.0 meters, the nearest blind area is only 0.2m, and the field of view Angle is as high as 62 degrees horizontal and 48 degrees vertical (myopia field 233mm*90mm, farsightedness field 1220mm*900mm), which significantly expands the effective movement space of the robot and can easily measure large-size objects. It brings more space and flexibility to the robot operation under space limitation, and further improves the precision of close operation in hand-eye coordination.

Compact and lightweight, light load more flexible
One of the smallest 3D industrial cameras in the industry, with a compact structure (140.6mm*47mm*60mm) and light weight (555g), it is very easy to integrate in the front end of a small robot arm, easily cope with small Spaces and multi-machine deployment scenarios, and further expand the application scenario of collaborative robots +3D vision. The PS800 also continues the stable and reliable characteristics of the Tuyen product structure, without camera calibration maintenance and any other form of product maintenance during the whole life cycle.

Hardware ISP, faster and better image output
Built-in hardware ISP, achieve 5M pixel RGB image quality optimization and HDR function, better support 2D image-based AI recognition, more support 2D+3D joint optimization algorithm.

Good software development support
Consistent with other camera products of Tuyang, all sensor underlying algorithms are completed locally in the camera, and the camera network port directly outputs real-time depth map or point cloud data, which does not occupy the computing resources of the host computer, and the host computer only needs to run the standard version SDK of Tuyang. Tuyak’s SDK and RVS software platform are standard versions that support all Tuyak 3D cameras, allowing existing developers to seamlessly get started with new cameras without additional learning costs.
