Industrial environments are increasingly demanding devices that are smaller, more powerful, more cost-effective, and safe and easy to use. When transferring current, signals and data to the printed circuit board, losses should be minimized while ensuring high stability. The same is true of the process control industry. In the process control industry, the number of device components that need to be connected via internal data infrastructure or IIoT is rapidly increasing. In response to these challenges in the process control industry, Weidmuller has introduced OMNIMATE® data class Enthernet-APL products.

In the process control industry, access to field data is increasingly dependent on Ethernet-compatible interfaces. The new Enthernet-APL technology enables direct access to the underlying field and equipment layers. Enthernet-APL ensures high-speed data transmission over long distances, simultaneously transmitting power and communication signals via a single twisted pair cable, supporting safe operation in hazardous areas. The equipment adopts APL standard certified interface to make full use of the advantages of new technology. Many Weidmuller products are already certified to the Enthernet-APL standard. This includes OMNIMATE® PCB components. These connectors can be mounted to the panel for on-site installation and assembly, using two-wire technology for reliable connection to field equipment. Realize real-time availability of equipment data. These components are equipped with proven joining technology, which enables fast, error-free installation through color-coded components.

AS-B875-002

Certified to the Enthernet-APL standard, Weidmuller products meet the demanding requirements of the process control industry. At a transmission rate of 10 Mbit/s, it can support transmission distances of up to 1000 meters, while providing power supply.
Enthernet-APL works with all IIoT devices and is compatible with all common protocols such as PROFINET, EtherNet/IP or EtherCAT. APL PCB components are economical and can replace traditional RJ45 and M12 interfaces. And the portfolio continues to grow.
OMNIMATE® PCB components are equipped with a variety of proven connection technologies. Whether it is PUSH IN line connection technology, SNAP IN squirrel cage connection technology, wire frame connection technology or spring terminal connection technology: all connections have high stable contact and vibration safety features. Color-coded signs help with proper installation.

In the process control industry, fast and reliable data transmission is becoming increasingly important. The development of IIoT devices requires highly secure, meticulously designed components of the future. To address this need, Weidmuller offers high-quality components that provide a clear added value for devices designed with OMNIMATE® data products. The whole process is designed to take into account a variety of important information, including products, possible applications, technical details and product data information. In addition, we help device manufacturers find the right solution through online catalogs, free sample services and innovative AppGuide. Weidmuller thus combines a number of decisive advantages in the development of equipment for the process control industry.
