Whether on the assembly line or on the machine, when it comes to the safety of the production area, the safety drawstring switch is a widely recognized and reliable solution that can trigger the scram function from any point on the drawstring to shut down dangerous work processes. The PSENrope puller switch with a rope length of up to 75 meters is suitable for safety protection in larger areas.
If the area to protect is relatively small, using PSENrope is overkill. Is there a better solution for smaller applications?
The PSENrope Mini was born. The PSENrope mini can provide safety protection for a conveyor belt or system by combining two different devices (a pulse-triggered scram and an integrated scram button on the component) in a compact design of metal or plastic, especially suitable for confined Spaces, and rugged.
The difference between PSENrope mini and PSENrope
The PSENrope mini is a particularly compact and cost-effective pull rope switch with a pull rope length of 30 meters, which is suitable for relatively small applications. Due to its compact structure, the PSENrope mini does not have the quick adjustment function and pull rope tension display feature of the PSENrope.

The PSENrope mini has its own advantages in the way it is installed. The PSENrope mini is available in both straight and curved (left or right bent) versions, and due to its smaller size, the installation of the PSENrope mini is more flexible and simple in a variety of assembly situations. In addition, the button of PSENrope mini has two functions: emergency stop or reset. The button function of PSENrope is only emergency stop.

The emergence of PSENrope mini makes the user more flexible in the selection of safety rope switches, and can choose more suitable products according to the field environment and use needs.

“Structure Profiling” for PSENrope mini

The PSENrope mini consists of a safety rope pull off, a red rope and a support point.

1. Emergency stop/reset button

Emergency stop button: The emergency stop button is directly on the device and can be directly on the switch to achieve emergency stop

Reset button: In the case of covert installation, scram on the device is not allowed, we provide a device with a reset button “only”

2. Type of rope head

3 kinds to choose from: straight head, right elbow, left elbow

3. Configure multiple contact types

Up to 4 contacts for monitoring emergency shutdown function. The contact configuration includes 2 nos and 2 NCS

4. Connect the M20 cable inlet hole from the lower end

5. Type of shell

Materials and metals

The pull device of the safety rope pull switch is connected to a wire rope, and pulling the rope can trigger the emergency stop function. The rope traction system integrates spring pre-tightening, which triggers the lock and emergency stop function immediately in the event of a rope break or a loose rope being untied. After triggering, the safety contact remains locked. After eliminating hazardous conditions and checking the entire rope length of the machine, the system can be manually reset to operational readiness. If necessary, the rope section can also be retightened during operation by adjusting the screws/turnbuckle.
The emergency stop button can also be pressed in dangerous situations, the safety contact opens in the same way as the pull wire, and the switch is locked in place. After the dangerous situation has passed, the system can be manually reset to the operational ready state by pulling the emergency stop button.
The cable activation switch is locked, and when the safety contact is open, the switch can be reset to the ready state by pulling the release button.
PSENrope mini selection “secret”
You know what? We can “read” information about this product from the model of the safety pull rope switch.
We use the model PSEN rsm 1.0-300-0-0-0 to illustrate.
PSEN rsm 1.0-300-0-0-0, PSEN rsm indicates that this product belongs to the Peel magnetic sensor safety rope switch mini series.

PSEN rsm 1.0-300-0-0-0 1 indicates that the shell material is metal, and 2 indicates that the shell material is plastic.

PSEN rsm 1.0-300-0-0-0 0 indicates that the contact is normally 2 open 2 normally closed, 1 indicates that the contact is normally 1 open 1 normally closed, 2 indicates that the contact is normally 2 closed, 3 indicates that the contact is normally 1 open 3 normally closed.

PSEN rsm 1.0-300-0-0-0, 300 indicates the maximum spring force of the rope.

PSEN rsm 1.0-300-0-0-0:0 indicates the emergency stop button, and 1 indicates the release button.

PSEN rsm 1.0-300-0-0-0 0 indicates that the head is pulled vertically, 1 indicates that the head is pulled vertically to the right, and 2 indicates that the head is pulled vertically to the left.

PSEN rsm 1.0-300-0-0-0 0 Indicates that the connection mode is M20 connection thread.
