3BHE021887R0101 UBC717BE101 IEC 61850 Communication Module

Advanced Protection Relay Systems

Main Features and Benefits

The ABB UBC717BE101 communication module enables seamless integration of protection relays into modern IEC 61850-based substation automation systems. Designed specifically for ABB’s RELION protection platform, this module provides high-speed process bus communication with deterministic performance for mission-critical protection schemes. Its dual optical Ethernet ports support redundant ring topologies, ensuring communication reliability even during network disturbances.

UBC717BE101

Key operational advantages include:

• Precision time synchronization: IEEE 1588 Precision Time Protocol support with ±1μs accuracy
• Sampled value streaming: IEC 61850-9-2LE implementation for high-resolution measurement data
• Cyber security: Integrated security features including role-based access control and audit logging

The UBC717BE101 features non-volatile memory for configuration persistence during power interruptions and supports firmware updates without module removal. Its rugged design withstands harsh substation environments with extended temperature operation and high immunity to electromagnetic interference. The module’s diagnostic capabilities provide real-time monitoring of communication health, including fiber optic link quality and protocol performance metrics.

Substation Automation Specialists

As certified ABB system integrators with IEC 61850 expertise, we provide comprehensive digital substation solutions from engineering design to commissioning. Our engineers deliver configuration services including SCL file management, GOOSE mapping, and network architecture optimization for your specific protection requirements.

We support every UBC717BE101 module with premium 12-month coverage:

• 24/7 technical support with 4-hour response SLA
• Configuration backup and version management
• Firmware updates with compatibility validation
• On-site commissioning assistance

Need legacy system integration? Email our automation engineers for hybrid solutions. Response guaranteed within 2 business hours.

Application Areas

The ABB UBC717BE101 excels in digital substation applications including transformer protection, busbar protection, and feeder management systems. Its IEC 61850 compatibility makes it essential for modern power utilities implementing process bus architectures, renewable energy integration, and smart grid initiatives.
