Description
Product details:
Product ID:3ASC25H214 ABB Type Designation:DATX 130 Catalog Description:DATX 130; Rotor feedback board Long Description:DATX 130 Country of Origin:United States (US) Sweden (SE) Customs Tariff Number:85371098 Invoice Description:Rotor feedback board Product Net Weight:0.14 kg
ABB DATX130 3ASC25H214 Rotor feedback board Combinatorial logic
The combinatorial logic controller is composed of sequential circuit, instruction decoding circuit and combinatorial logic circuit. Through the instruction decoder to determine the current execution of the instruction, combined with the timing circuit generated by the beat, together as the input result of the combinative logic circuit output corresponding control signals. Combinatorial logic controller is composed of complex combinatorial logic gate circuit and flip-flop, and has high execution speed, so it is widely used in computer structures such as RISC. [1]
Design steps:
1. Design the instruction system of the machine: specify the types of instructions, the number of instructions and the format and function of each instruction;
2. Preliminary overall design: such as register setting, bus arrangement, computer design, connection relationship between components, etc.;
3. Draw instruction flow chart: mark the operation of each instruction at what time and what part;
4. Arrange operation schedule: that is, decompose each operation into micro-operation according to the instruction flow chart, and list the micro-operation to be carried out by the machine according to the time period;
5, list the microoperation signal expression, simplification, circuit realization.
Recommended model:
3BSE021447R1 ABB processor
3BSE021443R1 ABB processor
3BSE013230R1 ABB application
3BSE045584R1 ABB Operating system
3BSE023675R1 ABB test tool
3BSE008510R1 ABB minicomputers and PCS
3BSE008508R1 ABB system design
3BSE031155R1 ABB entry system
PP835 ABB Japan established
