Description
Order product number ANR5131
Model ANR5131
Compare output type unitary comparator
Analog output ±5V/F.S.(Max. 2mA)
Output resistance 50Ω
Zero adjustment range ±10% of F.S.
Temperature drift (using sensors, controller components) within ±(0.03% of F.S.)/ ° C
Reaction frequency (-3dB), reaction time (10-90%) 1kHz 0.4ms/100Hz 4ms/10Hz 40ms (switching)
Compare output NPN open collector 2 points (100mA 30V DC below, residual voltage 1.5V below)
(Note) : PNP output model is also available.
ANR5131
Comparative output: The difference should be less than 0.15% of F.S.
Alarm output NPN open collector 1 point (100mA 30V DC below, residual voltage below 1.5V)
(Note) : PNP output model is also available.
Optical monitoring output ±5V
Compare synchronous input No voltage input (do not compare outputs when grounded)
Displacement display sensor: Measurement RANGE display LED(RANGE)
Gain switching AUTO/LOW(switch switching)
Prevent mutual interference between 2 groups can be prevented
(Note) : When using this mode, linearity, resolution, and reaction performance may be reduced.
Operating voltage range 12 ~ 24V DC +10/ -15% including pulsation 0.5V(P-P)
Current consumption (with sensor and controller components) less than 250mA (with 12V DC input), less than 125mA (with 24V DC input)
Weight (including cable) Body weight: about 180g
Insulation resistance (initial value) Between external DC input and sensor metal parts (except connector metal parts), more than 20MΩ (DC500V based high resistance meter)
