CI860K01 3BSE032444R1 Field bus HSE interface

Manufacturer :ABB
Product number :3BSE032444R1
Product model :CI860K01 Foundation Fieldbus HSE interface
Communication speed :100000/1000000 kbit/s
The maximum unit on the CEX bus :12
Packaging includes :- CI860, communication interface, – TP860, substrate
Connector :RJ-45 Internal Thread (8 pins)
Typical power consumption is 24 V. : Typical value 100 mA
Operating temperature :55℃
Protection level: IP20 according to IEC 529 EN60529
Dimensions (H x W x D), approximately 18.5 cm x 5.9cm x 12.75cm

AC 800M is a hardware platform comprising individual hardware units, which can
be configured and programmed to perform multiple functions.
Once configured and programmed, the AC 800M effectively becomes the AC 800M
or AC 800M HI controller.
The hardware units that form the AC 800M and AC 800M HI Controllers are:
• Processor units (including baseplate)
(PM851/PM851A/PM856/PM856A/PM860/PM860A/PM861/PM861A/
PM864/PM864A/PM865/PM866/PM891)
• High Integrity Processor Unit
(consists of PM865 and SM810/SM811 with corresponding baseplates)
• Communication interfaces for different protocols (including baseplates)
(CI851/CI852/CI853/CI854/CI854A/CI855/CI856/CI857/CI858/CI860/
CI862/CI865/CI867/CI868/CI869/CI871/CI872/CI873)
• CEX-Bus Interconnection Unit
(BC810)
• Power supply units, providing various power output levels
SD831/SD832/SD833/SD834/SS823/SS832)
• Battery back-up unit
(SB821/SB822)
The SB821 is not supported with PM891.

PM851 is equivalent with PM856 unless stated otherwise.
PM851A is equivalent with PM851 unless stated otherwise.
PM856A is equivalent with PM856 unless stated otherwise.
PM860A is equivalent with PM860 unless stated otherwise
PM861A is equivalent to PM861 unless stated otherwise.
PM864A is equivalent to PM864 unless stated otherwise.
