DS200CTBAG1ADD GE Mark V Terminal Board
The DS200CTBAG1ADD is a terminal board designed for use within the GE Mark V Speedtronic system. The Speedtronic line was created by General Electric for the control of both large and small gas and steam turbine systems. The MKV can be designed with either Simplex or TMR/triple modular redundant architecture to meet the needs of the connected turbine system. These circuit boards are no longer fabricated and distributed by GE but can be purchased through AX Control as fully tested and refurbished models.
The DS200CTBAG1ADD is a long, narrow board with only a few types of components. It is drilled at each corner and along its long edges to allow for mounting hardware and other connections. Two of these drill holes are ringed with a conductive material. The board is marked with identifying codes including the board ID number and the company logo.
DS200CTBAG1ADD
The DS200CTBAG1ADD is an Analog Termination Module. It is typically located within the core. The board has multiple connectors, including two COREBUS connectors (JAI and JAJ.) The DS200CTBAG1ADD has two double-stack terminal strips located on one long board edge with multiple connectors on each terminal strip. There are five vertical pin cable connectors, two vertical pin header connectors, and a 9-pin male serial connector.
Other components on the DS200CTBAG1ADD include resistor network arrays, relays, transistors, over twenty metal oxide varistors (MOVs,) over a dozen jumper switches, along with a number of capacitors and resistors. For additional information, please refer to technical support products originally provided by General Electric.
