DSMB-02C 3AFE64666606 ABB ethernet adapter

Description

DSMB-02C 3AFE64666606 ABB ethernet adapter
DSMB-02C 3AFE64666606 ABB ethernet adapter
DSMB-02C 3AFE64666606 ABB ethernet adapter

The output circuit design of the PLC control system. According to the requirements of the production process, the start and stop of various indicator lights, frequency converters/digital DC speed controllers should use transistor output, which is suitable for high-frequency action and has a short response time; if the output frequency of the PLC system is less than 6 times per minute, Relay output should be the first choice. Using this method, the design of the output circuit is simple, and the anti-interference and load capacity are strong.

If the PLC output has inductive loads such as electromagnetic coils, when the load is powered off, it will cause a surge current impact on the output of the PLC. For this reason, the DC inductive load should be connected with a freewheeling diode next to it, and the AC inductive load should be connected in parallel. Surge absorbing circuit can effectively protect PLC.

When the PLC scanning frequency is less than 10 times/min, the relay output mode can be used, or the PLC output can be used to drive the intermediate relay or solid state relay (SSR), and then drive the load.
