LDGRB-01 3BSE013177R1 ABB Processor module

Description

LDGRB-01 3BSE013177R1 parameter：

Start-up behavior with missing or damaged
I/O module on hot swap terminal unit TU5xx-H
Remote I/O station is not starting
Start-up behavior with wrong I/O module type
on any terminal unit
Remote I/O station is not starting
Diagnosis of presence of
hot swap terminal unit
Information is available in Modbus registers of
the communication interface module which
can be accessed by the application program
Diagnosis of hot swap capability of I/O module
mounted on hot swap terminal unit
Information can be obtained by reading
LDGRB-01 3BSE013177R1 Modbus registers in the communication interface module. Those Modbus registers contain:
● Diagnosis in case that a not hot-swappable I/O module is plugged on a hot
swap terminal unit
● Diagnosis In case that in a mixed configuration with at least one hot swap terminal
unit an I/O module, that must not be used
in a hot swap configuration, is mounted on
any terminal unit of the configuration
● Production data and version index of the
modules
Diagnosis while hot swap module is pulled or
module (mounted on hot swap terminal unit)
has stopped working
Diagnosis is available in Modbus registers in
the communication interface module
Input state in process image of controller while
module is pulled or module is not operational
Input = ZERO
Diagnosis after plugging the I/O module on
the hot swap terminal unit
Diagnose “diagnosis gone” is available in
Modbus registers in the communication
interface module
