MVIEW 1TGE120028R0010 Human System Interface

Description

MVIEW 1TGE120028R0010 Human System Interface

Software Modules
MLink contains diferent software modules depending on its initial configuration. The softwaremodules are available on request.
Following software modules are available:
Web Server
OPC Server (DA & AE)
Fieldbus
Time SynchronizationRedundant Operation
If a specific module is not available on the MLink, please contact your local ABB LVS Salesorganization should this be required.
Web Server
A Web Server can be activated inside Link, Throuah network connection web interfaceinformation can

be displayed on MView or a PC using web browser software. For details aboutVVeb Interface see the document:
MNS iS Interface Manual Web Interface
OPC Server
With MNS iS an OPC Server (DA & AE) is available. The sotware is typically installed on aserver as part

of the automation control system. The software installation program is deliveredseparately. lf activated, the

MLink functions as a data provider for the MNS iS OPC Server. Fordetails about OPC Server see the document:
MNS iS Interface Manual OPC Server.
Fieldbus
MLink can include Fieldbus communication to DCS. The type of Fieldbus must be selectedbefore ordering the

MLink type. The Fieldbus specific information (PROFlBUS, MODBUS etc.)can be found in the following documents:
MNS iS Interface Manual Profibus
MNS iS Interface Manual Modbus
MNS iS Interface Manual Profinet lO

1TGE120026R0103

Time Synchronization
In the MControl Alarms and Events can be provided with a time stamp. The time and date isreceived on MContro/ from

MLink via the intemal switchgear bus. in order to provide the correcttime and date the Time Sync option must be

activated in MLink and it may require a time serverin the switchgear control network.
The protocol used for time synchronization is the standard network time protocol (NTP).
Time Sync must be activated through the ABB Engineering Tool.
Option 1
A standard network component is installed which can provide the time signal as NTP Server.Such a NTP Server can

be a computer or network server as well as Ethernet switches. As anoption, this NTP Server can be equipped with a GPS Receiver to provide accurate time for thelocation.
In case of Option 1, Time Server hardware is not part of MNS iS and has to be suppliedseparately.
