1394C-SJT05-T-RL multi-axis motion control 1394C-SJT05-D

The 1394C-SJT05-T-RL, a member of 1394 Allen-Bradley motion control series, is a multi-axis motion control with terminations, EMI filtering, and smart power. The 1394C-SJT05-T-RL has IMC S Class (GMC turbo) integrated motion control. GMC turbo provides more GML memory and executes programs quickly. This servo controller offers 64 KB of memory, a 32-bit processor, and a direct link to the small logic controller (SLC). The 1394C-SJT05-T-RL system uses the SLC or backplane interface to transfer I/O data bits. The 1394C-SJT05-T-RL provides straight line connections at 360 to 480 Volts AC of three-phase input power, eliminating the need for a transformer. It has efficient IGBT power conversion, a slide-and-lock feature, and module-to-module connection systems.  This module can support up to four axes and saves considerable panel space.

Add to quote
Category:

Description

1394C-SJT05-T-RL multi-axis motion control 1394C-SJT05-D

Product description

The 1394C-SJT05-T-RL, a member of 1394 Allen-Bradley motion control series, is a multi-axis motion control with terminations, EMI filtering, and smart power. The 1394C-SJT05-T-RL has IMC S Class (GMC turbo) integrated motion control. GMC turbo provides more GML memory and executes programs quickly. This servo controller offers 64 KB of memory, a 32-bit processor, and a direct link to the small logic controller (SLC). The 1394C-SJT05-T-RL system uses the SLC or backplane interface to transfer I/O data bits. The 1394C-SJT05-T-RL provides straight line connections at 360 to 480 Volts AC of three-phase input power, eliminating the need for a transformer. It has efficient IGBT power conversion, a slide-and-lock feature, and module-to-module connection systems.  This module can support up to four axes and saves considerable panel space. The 1394C-SJT05-T-RL is a 5-Kilowatt controller with a peak power output of 28 Kilowatts and a 99% efficiency. In addition, it has a continuous current output of 7.36 Amps, an intermittent current output of 15.0 Amps, a line loss ride through of 20 milliseconds, and an AC input current of 6.5 Amps.

1394C-SJT05-D

Product parameter

Technical Specifications for 1394C-SJT05-T-RL

Manufacturer Rockwell Automation
Brand Allen-Bradley
Part Number/Catalog No. 1394C-SJT05-T-RL
Product Line Servo Controller
Module Type System
Power Rating 5 Kilowatt
Input Phase 3 Phase
Series Enhancements Terminations, Filtering (EMI), and Smart Power
Factory-Installed Options GMC Turbo- IMC S Class
GMC Options AxisLink and Remote I/O
Input Voltage 360-480AC Volts
Nominal Bus Output Voltage 380/460 Volts 530/680 Volts DC
Continuous Power Output 380/460 Volts 4/5 Kilowatts
Peak Power Output 28 Kilowatts
Efficiency 99%
Continuous Current Output 7.36 Amperes
Peak Current Output 15.0 Amperes
Line Loss Ride Through 20 ms
Rated AC Input Voltage 324-528 Volts AC, 50-60 Hertz, 3 Phase
AC Input Current 6.5 Amperes
Weight 23.5 lbs (10.68 kg)
Dimensions 13.8 x 11.0 x 5.91 in (350 x 280 x 150 mm)

Application field

The rated input voltage of the 1394C-SJT05-T-RL is 324 to 528 Volts AC and it can run at 50 to 60 Hertz. Moreover, it has digitally-adjusted compensation for velocity and current loop, which serves a range of system inertias. It has two analog test outputs that can connect to critical system parameters for diagnostics. The 1394C-SJT05-T-RL must be installed in a clean and dry enclosure. When using well-ventilated enclosures with ambient air, use the appropriate filtering to protect against contamination. The ambient air temperature is between 0 and 50 degrees Celsius (32 and 122 degrees Fahrenheit) and the ambient humidity is between 5% and 95% and non-condensing.
