Description
Ethernet connectivity is achieved via the Dual RJ45 ports that supports Ethernet I/P protocol. These
ports support Linear for simple communication network and Ring topology for High availability network
. It supports 10/100 Mbps communication rate and capable of interfacing up to Eight (8) Flex I/O modules
to the controller connected in the network.
The 1794-AENTR is directly mounted to a DIN rail. Inspect installation point for excessive vibration and shock. Operating vibration and shock acceptable for the module is 5g and 30g respectively. An external power supply with nominal supply voltage of 24VDC must be connected to the power terminals of the 1794-AENTR to energize the module. Acceptable voltage supply range is 19.2…31.2V DC, including 5% AC ripple. Conductor wire size recommended when establishing connections to the module is 0.33…3.31 sq. mm or 22…12 AWG, stranded copper wire with insulation rating of 75 °C or 167 °F or higher and maximum insulation thickness of 1.2 mm or 3/64 in.
1794-AENTR
The Allen-Bradley 1794-AENTR is a Flex I/O dual-port EtherNet/IP redundant media adapter module. It can handle up to 8 I/O modules and it has a communication rate of 10 to 100 Mbps. It comes with an inrush current of 18 Amps for 2 milliseconds. It has a nominal input voltage of 24 Volts DC and an input voltage range of 19.2 to 31.2 Volts DC, which includes the 5% AC ripple. This module has a maximum power consumption of 500 mA and one of 400 mA at 24 Volts DC and a maximum Flexbus output of 640 mA at 5 Volts DC.
