2090-CSBM1DF-18AA25 Kinetix Single cable
Product Description
The Allen-Bradley (A-B) brand model 2090-CSBM1DF-18AA25 cable is A single-motor cable designed for Kinetix 5500 series servo drives with the following product details:
Cable type: This is a standard non-flexible cable with an industrial TPE sheath and orange color (DESINA, RAL 2003).
Cable specifications: A 1000V hybrid cable with four power cords, two feedback (digital communication) wires and two brake wires.
Wire size: AWG 18, with a weight of about 0.212 kg per meter.
Cable length: 25 meters.
Drive end: Flight Lead (DF) designed for Kinetix 5500 servo drives.
Motor end connector: SpeedTec DIN (M1) single cable plug, compatible with Kinetix VP motors.
IP level: Optional, IP5x without shaft seal, IP66 with shaft seal.
This cable is designed to provide stable power and signal transmission in industrial environments while ensuring the braking function of the motor. It is suitable for applications that require high flexibility and durability.
2090-CSWM1DF-14AA09
Product parameter
Cable model: 2090-CSBM1DF-18AA25
Description: Kinetix Single cable, DF single cable for K5500, 18 AWG, TPE, standard non-flexible, single motor power supply and feedback with brake wire
Wire specification: 18 AWG
Cable material: Industrial TPE, orange skin
Cable length: 25 meters
Cable weight: about 0.212 kg per meter
Drive end connector: Flight Lead (DF) for Kinetix 5500 servo drives
Motor connector: SpeedTec DIN (M1) single cable plug
Maximum cable length: For Kinetix 5500 servo drives, the maximum cable length is 50 m (164 ft), in increments of 1.0 m (3.3 ft)
Cable configuration: 1000V hybrid cable with four power cables, two feedback (digital communication) cables and two brake cables
IP Rating: Depending on whether a shaft seal is used, a protection rating of IP5x (without shaft seal) or IP66 (with shaft seal) is available
Application field
Servo motor drive system: Cables are used to connect the Kinetix 5500 servo drive to the Kinetix VP series motor, transmitting power, feedback and braking signals.
Industrial robotic arms: In robotic arms on automated production lines, such cables ensure precise control of the movements of the robotic arms.
Conveying system: In material handling and conveying systems, this cable is used to control the motor to achieve precise adjustment of the speed and direction of the conveyor belt.
Packaging machinery: In machinery that requires precise control of the packaging process, such as sealing machines, balers, etc., this cable can ensure the stability and response speed of the motor operation.
Machine control: Used in CNC machine tools, this cable ensures accuracy and repeatability in complex machining.
