Description
The 2711P-K6C20D terminal from Allen-Bradley is a PanelView Plus 6 terminal designed for industrial installations where DC power is available. The 2711P-K6C20D terminal is an HMI device with a keypad and color display. The environmental specifications for the units include an operating temperature range of 32 to 131 degrees Fahrenheit and a non-operating temperature range of -13 to 158 degrees Fahrenheit. The heat dissipation for the unit is 85 BTU/hour. The maximum recommended altitude for installation is 6561 feet. The unit’s enclosure is a NEMA/UL type 12, 13, 4X enclosure and it is meant for indoor use only. The 2711P-K6C20D terminal has an approximate weight of 725 grams. The dimensions of the unit are 6.58 x 10.47 x 2.68 inches and the cut-out dimensions are 5.61 x 9.5 inches.
2711P-K6C20DOperator Interface Terminal
The 2711P-K6C20D terminal is designed for DC input between 18 and 30 Volts DC. The unit requires a Class 2 or a SELV or PELV power supply. The typical power consumption is 9 Watts (0.375 Amps at 24 Volts DC) while the maximum power consumption is 15 Watts (0.6 Amps at 24 Volts DC). The 2711P-K6C20D terminal is a Series 600 module and it includes a keypad for operator data input. The unit’s display screen supports 18-bit color graphics with a 320 x 240 resolution. The size of the display is 5.5 inches. A battery-backed real-time clock provides timestamps for critical data. The unit comes with a communication module which includes multiple communication ports, including USB, RS-232, and Ethernet port.
