Description
The 2711P-B4C20D8 PanelView Plus Compact is an operator interface device by Allen-Bradley which allows for full machine
interface using the 3.5-inch color LCD touchscreen with a diagonal display area of 2.8 x 2.1in and a display resolution of 320 x 240. The
2711PC-B4C20D8 offers users a display brightness of 200 cd/m2 Nits and an LED backlight with a standby time of about 50,000 hours.
It also allows users to input information through the Functional (F1 to F8), Navigational, and Numerical Poly-domed membrane Keypad
with 1 million presses actuation rating and 340G operational force. It comes with a ±2 minutes per month accuracy and a battery-aided
internal clock with 5 years of battery life at 25 °C. The 2711PC-B4C20D8 stores users’ programmed application settings in the 512MB
(expandable) internal flash memory, and uses the 256MB RAM for processing applications. Connection with other peripheral devices is
achieved through the USB 2.0 port, and it also has a base 10/100 Ethernet port for Network Communication. The 2711PC-B4C20D8 uses
a DC power source, with a supply rating of 18-30V DC input voltage and 25W (max.) power consumption at 24V DC and 1.0A. It dissipates
84 BTU/Hr heat when operational, and is enclosed in a NEMA Type 12, 13, 4X and IP65 rated enclosure. It can be installed at an altitude
of about 2000m without de-rating and is built to withstand an operational shock of 15G at 11ms. The 2711PC-B4C20D8 weighs approximately 1.24lb and its dimensions are 6 x 7.28 x 3.54in.
2711PC-B4C20D8
The 2711P-B4C20D8 is part of the PanelView Plus 6 operator terminals. The main features of this operator terminal includes a
3.5-inch colored Active Matrix Thin Film Transistor (TFT) display, embedded Ethernet, RS-232 and USB interfaces, and dual input interfaces such as touchscreen and keypad interfaces.
The 2711P-B4C20D8 is powered by an external supply voltage of 18-30 Volts DC. It has a power consumption rated at 15 Watts
maximum (0.6 Amperes at 24 Volts DC) and 9 Watts typical (0.375 Amperes at 24 Volts DC). General purpose 24 Volt DC power
supplies may be used – however, Allen-Bradley recommends use of 1606-XLE120E, SELV, or PELV isolated power supply for
non-isolated power source, specifically intended for PanelView Plus 6 400 and PanelView Plus 6 600 DC-powered operator terminals.
