Description
Product Overview
The 6181P-12TPXP is a high-performance industrial-grade PoE+ Ethernet switch, specifically designed for harsh environments. It supports 12 Gigabit ports (including 8 PoE+ power supply ports), features IP67 protection rating, wide temperature operation capability and redundant power input, and is suitable for scenarios such as intelligent security, industrial automation and outdoor Internet of Things.
Technical Specification Sheet
Details of category parameters
Basic configuration
The number of ports is 12×10/100/1000 BASE-T RJ45
PoE+ Port 8 ports (Port 1-8)
Uplink port 2×100/1000 BASE-X SFP (pluggable optical module)
PoE characteristics
PoE standard IEEE 802.3af/at
The maximum power of a single port is 30W
The maximum power budget for the entire machine is 240W
Performance parameters
The switching capacity is 24Gbps
The packet forwarding rate is 17.8Mpps
MAC Address table 8K
Reliability
Protection grade IP67 (metal casing)
Operating temperature: -40°C to 75°C
Dual redundant DC power input: 12-48V (supports reverse connection protection)
The MTBF is over 500,000 hours
Management function
Management methods: Web management /CLI/SNMP v1/v2c/v3
Network protocols: VLAN, QoS, IGMP Snooping, STP/RSTP/MSTP
Mechanical properties
Installation method: DIN rail/Wall-mounted
Dimensions (W×H×D) : 135mm × 105mm × 55mm
Weight: 1.2kg
6181P-17A2MW71DC
Core functional highlights
1. Industrial-grade robust design
• All-metal housing, shock-resistant/vibration-resistant (IEC 60068-2-6/27)
Fanless heat dissipation, dust and water resistant (IP67)
2. Intelligent PoE management
• Support PoE priority scheduling (power failure protection for critical equipment)
Real-time power monitoring and overload protection
3. Network redundancy technology
• Supports ring network protocol (ERPS/G.8032)
Self-healing time is less than 20ms
4. Flexible deployment
• SFP optical port supports single-mode/multi-mode modules (transmission distance: 550m for multi-mode, 20km for single-mode)
• Wide-voltage power input (12-48VDC) is compatible with vehicle-mounted/solar power supply
Typical application scenarios
Field application cases
Intelligent security 8-channel POE-powered camera networking (dome camera/bullet camera) + fiber optic transmission back to the monitoring center
Industrial control production line PLC equipment networking + real-time data transmission of machine vision system
Smart Transportation Outdoor Electronic Police System (Power Supply for License Plate Recognition Cameras + Data Transmission)
Energy Internet of Things Photovoltaic Power Station Environmental Monitoring Sensor Network (Temperature/irradiance/Inverter status Collection)
Ordering information
Model description: Optional accessories
6181P-12TPXP host (including DC power terminal) –
The SFP-GBIC-550 multimode optical module (850nm/550m) needs to be ordered separately
The SFP-GBIC-20KM single-mode optical module (1310nm/20km) needs to be ordered separately
The DIN Rail-Kit DIN RAIL mounting KIT is included in the standard packaging
