106M1081-01 BENTLY Controller module

Description

106M1081-01 BENTLY details：

106M1079-01 Universal AC Power Supply Module
106M1081-01 Universal AC Power Input Module
129486-01 Legacy High Voltage DC Power
Supply Module
129478-01 Legacy High Voltage DC Power Input
Module
133292-01 Legacy Low Voltage DC Power
Supply Module
133300-01 Legacy Low Voltage DC Power Input
Module
114M5329-01 High Voltage DC Power Supply
115M7750-01 High Voltage DC PIM
114M5330-01 Low Voltage DC Power Supply
114M5335-01 Low Voltage DC PIM
01720025 Replacement Fuse (for both
AC Power Input Module and Legacy
High Voltage DC Power Input
Module)
01720045 Replacement Fuse (Low Voltage DC
Power Input Module and Legacy Low
Voltage DC Power Input Module)
120M3877 Replacement Fuse
Fast blow rated at 5A/500 Vac
Size 6.3 x 32 mm
(Universal AC Power Input Module)
131150-01 Power Supply Blank Front Panel (qty
1, includes screws)
128085-01 Power Supply Rear Input Connector
Cover (qty 1) Order part 04310251 for
screws.
04310251 Screw for Power Supply Input Cover
(qty 2)
129767 3500/15 Power Supply User Guide
118M0915-01 Replacement connector for Universal
AC Power Input Module

The 3500/15 AC and DC Power Supplies are half-height modules and
must be installed in designated slots on the left side of the rack. The
3500 rack can contain one or two power supplies with any combinations
of AC and DC. Either supply can power a full rack.
When two power supplies are installed in a rack, the one in the lower
slot acts as the primary supply, and the other in the upper slot acts as
the backup supply. If installed, the second supply is the backup for the
primary one.
Removing or inserting either power supply module does not disrupt
operation of the rack as long as a second power supply is installed.
The 3500/15 AC and DC Power Supplies accepts a wide range of input
voltages and converts them to voltages acceptable for use by other
3500 modules. The following power supplies are available with the 3500
Series Machinery Protection System:
l Universal AC Power
l High Voltage DC Power Supply
l Low Voltage DC Power Supply
