3500/25 149369-01 Speed sensor Bently

Frequency response:
4.5Hz to 2,000Hz (270 to 120,000 cpm) ±3.0dB 6.0Hz to 1,000Hz (360 to 60,000cpm) ±0.9dB

Add to quote
Category:

Description

The Bentley Bently330525Velomitor and 330500 parameters are not very different, it can be said that the Bently330525Velomitor*XA (Extended Application) is a rugged version of the Bently Nevada 330500 speed sensor. It has a 316L stainless steel housing, the best protective coupling and cable assembly, and does not require a cabinet for installation.
The Bentley Bently330525Velomitorr XA and cable assembly can be used in humid environments and meet the requirements of IP-65 and NEMA4X when properly installed.
Bentley Bently330525Velomitorr Electrical characteristics
Sensitivity:

3500/25 149369-01

3.94mV/mm/s (100mV/in/s) ±5%
Frequency response:
4.5Hz to 2,000Hz (270 to 120,000 cpm) ±3.0dB 6.0Hz to 1,000Hz (360 to 60,000cpm) ±0.9dB
Temperature sensitivity:
Typical values in the operating temperature range are -14% to +7.5%
Speed range:
1270mm/s (50in/s) peak
Lateral sensitivity:
Less than 5% of sensitivity
Amplitude linearity:
±2% to 152mm/s (6in/s) peak
Installation resonance frequency:
Greater than 12kHz
