3500/34 125966-01 TMR relay module

Product details:

How the TMR Relay Module works :3500/34 The TMR relay module consists of two main components: the TMR relay module (two) and the TMR Relay I/O module. After programming, two TMR relay modules perform the same function in parallel, effectively providing redundant functionality between the two.

Specifications Input power consumption: Typical value 9.6 watts. The output TMR relay module contains six leds for AC operation. OK LED: Lights up when the module is working normally. TX/RX LED: Send and receive. Blinking The communication between the module and other modules in the frame is normal. Channel alarm led: Light up when the relay channel is in alarm state. Relay: Three type double pole double throw (DPDT) relays are connected in a single pole single throw (SPST) configuration. Arc suppressor is not supported.

Spare parts

125966-01 3500/34 TMR Relay module.

125704-01 TMR Relay I/O module.

04425545 Ground Wrist Strap (Disposable)

129771-01 TMR Relay Module Manual. Order instructions

3500/34-01-00

3500/34-01-01
