Name: 5ACPCI.ETH3-01 Industrial Ethernet Communication Card
Availability: InStock

5ACPCI.ETH3-01 Industrial Ethernet Communication Card

Parameter	Value
Product Model	5ACPCI.ETH3-01
Manufacturer	B&R Automation
Product Type	Industrial Ethernet Communication Card
Interface Type	PCI Express x1
Ethernet Ports	3x 10/100/1000 Mbps RJ45
Protocol Support	Powerlink, PROFINET, EtherNet/IP, Modbus TCP
Data Transfer Rate	Up to 1 Gbps per port
Real-Time Performance	<100 μs cycle time
Power Consumption	2.5W typical
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C
Certifications	CE, UL, cULus

Add to quote

Category: B&R

Mail：sales@xiongbagk.cn
Phone/Wechat/Whatsapp：+86 18059884797

Description

Technical Specifications

Parameter	Value
Product Model	5ACPCI.ETH3-01
Manufacturer	B&R Automation
Product Type	Industrial Ethernet Communication Card
Interface Type	PCI Express x1
Ethernet Ports	3x 10/100/1000 Mbps RJ45
Protocol Support	Powerlink, PROFINET, EtherNet/IP, Modbus TCP
Data Transfer Rate	Up to 1 Gbps per port
Real-Time Performance	<100 μs cycle time
Power Consumption	2.5W typical
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C
Certifications	CE, UL, cULus

Main Features and Advantages

The B&R 5ACPCI.ETH3-01 industrial communication card delivers high-performance networking for automation systems. Featuring three independent Gigabit Ethernet ports, this PCIe card enables simultaneous communication across multiple industrial networks with real-time performance under 100 μs cycle times. Its multi-protocol support includes POWERLINK, PROFINET, EtherNet/IP and Modbus TCP, providing exceptional flexibility for diverse automation environments.

5ACPCI.ETH3-01

Advanced synchronization: The 5ACPCI.ETH3-01 incorporates precision time protocol (PTP) support for nanosecond-level clock synchronization across distributed systems. This ensures perfectly coordinated motion control and data acquisition across multiple machines and production lines.

Robust industrial design: Engineered for 24/7 operation in demanding environments, the card features industrial-grade components with extended temperature tolerance. The optimized heat dissipation design maintains stable performance even at maximum data throughput.

Seamless integration: As part of B&R’s Automation Studio ecosystem, the 5ACPCI.ETH3-01 offers plug-and-play configuration with unified engineering tools. The card supports hot-plug capability for maintenance without system shutdown, minimizing production downtime.

Our automation specialists provide configuration support – email us for network integration guidance and compatibility verification.

Application Areas

The 5ACPCI.ETH3-01 excels in high-speed automation applications including packaging machinery, robotic cells, printing systems, and semiconductor manufacturing. Its multi-network capability makes it ideal for hybrid production lines combining equipment from different manufacturers, while the triple-port design enables network segmentation for improved security and performance.
