PR6423/10R-131+CON041 EPRO Pressure transducer

Description

PR6423/10R-131+CON041  erformance
Linear Measurement Range 2 mm (80 mils)
Initial Air Gap 0.5 mm (20 mils)
Incremental Scale Factor (ISF) ISO: 8 V/mm (203.2 mV/mil) ± 5%
@ temperature range 0 to 45°C
(+32 to +113°F)
Deviation from best fit straight line (DSL) ± 0.025 mm (± 1 mil)
@ temperature range 0 to 45°C
(+32 to +113°F)
Measuring Target
Minimum Shaft Diameter 25 mm (0.79”)
Target Material (Ferromagnetic Steel) 42CrMo4 (AISI/SAE 4140) Standard
Other (On Request)
Environmental, General
Protection Class IP66, IEC 60529
Operating Temperature Range Sensor incl. 1m Cable: -35 to +200°C
(-31 to 392°F)
Cable & Connector: -35 to +150°C
(-31 to 302°F)
Material Sensor Tip (PEEK Polyether Ether
Ketone), Case (Stainless Steel)
Cable (PTFE Polytetrafluoroethylene),
Connector (Brass, nickel-plated)
Weight (Sensor with 1m Cable) Approx. 100 grams (3.53 oz)
