43AP-F-A4-2-C pneumatic controller

The FOXBORO 43AP-F-A4-2-C (may also be labeled 43AP-FA42C or similar) is a pneumatic controller manufactured by FOXBORO for industrial control and process automation. The following is the detailed product information of this product:

Basic characteristic
High precision: With high precision characteristics, the accuracy of the input to the pointer is ±0.5% of the range, and the accuracy of the input to the output depends on the measuring element used.
High reliability: Designed for manufacturing, energy, infrastructure, industrial process control, building automation and other fields.
Fast response: Ability to respond quickly to changes in industrial processes
Connection and installation
Connections: Pressure and vacuum connections, R1/4 or 1/4 NPT, depending on specifications, for connections with upper limits up to 14 MPa (2000 psi, or 140 bar or kg/cm²). For connections with upper limits from 14 MPa to 70 MPa (10,000 psi, or 700 bar or kg/cm²), R1/2 or 1/2 NPT, depending on the specification. For connections with upper limits greater than 70 MPa, use 9/16-18 Aminco® connectors. Pneumatic supply and output connections are 1/4 NPT.
Mounting: Panel mounted for all controllers with internal mounting elements.
Physical specification
Housing: Made of fiberglass reinforced polyester mold with superior corrosion resistance. The doors are made of fiberglass reinforced phenol oxide with shatter-proof polycarbonate Windows that resist UV rays.
Finished: Housing is grey polyester; Doors are blue textured polyurethane.
Data label: Aluminum data label, secured inside the door with a pressure-sensitive adhesive, includes a customer label data space of up to 72 characters and Spaces.
Approximate mass: 4.8 kg (10.6 lb), excluding components
