Description
Product details:
Product No. : P0973CA
Model : FEM100 Fieldbus Expansion Module
The Fieldbus Expansion Module (FEM100) provides four Expanded Fieldbuses to the Field Control Processor 270 (FCP270). Each of the four Expanded Fieldbuses can accommodate up to thirty-two 200 Series Fieldbus Modules (FBMs).
Transmission Rate : 2 Mbps for 200 Series DIN FBMs
Input voltage range : 21 to 26 V dc
Consumption : 2.2 W (maximum)
Operating temperature : -20 to +70°C (-4 to +158°F)
Operating relative humidity : 5 to 95% (noncondensing)
Operating altitude : -300 to +3,000 m (-1,000 to +10,000 ft)
FEM100 mounts on a Two-Slot (P0973CG) or Four-Slot (P0973CN) Expansion Baseplate. These baseplates can be mounted on a vertical DIN rail. Refer to PSS 21H-2W6 B4 for details.
Dimensions (HxWxD), approx, : 11.4cm x 4.46cm x 10.5cm
- Input voltage range : 21 to 42 V dc
- Consumption : 5 W (max)
- Operating temperature : 0 to 70°C (32 to +158°F)
- Operating relative humidity : 5 to 95% (noncondensing)
- Operating altitude : –300 to +3,000 m (–1,000 to +10,000 ft)
- Cable material : MMF 62.5/125 um
- Cable lengths : 3m up to 2km, greater than 50m – user supplied
- Dimensions (HxWxD), approx : 11.4cm x 5.15cm x 14.7cm
- Shipping Weight : 3 Kg
Recommended model:
FBM231 4-channel serial communication redundant components 4 RS232/422/485 ports
FBM232 10/100MB Ethernet communication single card 1 10/100M RJ45 port
FBM233 10/100MB Ethernet communication redundant single card 1 10/100M RJ45 port
FBM237 redundant 8-channel 0-20MA output interface components optional redundant 8AO
FBM241 8-channel voltage monitoring input, 8-channel discrete output (external power supply) 8DI/8DO
FBM241b 8-channel voltage monitoring input, 8-channel discrete output (internal power supply) 8DI/8DO
FBM241c 8-channel contact input, 8-channel discrete output (external power supply) 8DI/8DO
FBM241d 8-channel contact input, 8-channel discrete output (internal power supply) 8DI/8DO
FBM242 16-channel contact output (external power supply) interface component (optional redundancy) optional redundant 16DO
