P0926GV | FBM231 | 16-Channel Analog Input Module

Product Model | P0926GV FBM231
Manufacturer | Foxboro (Schneider Electric)
Product Type | 16-Channel Analog Input Module
Input Signal | 4-20mA ±0.05% FS
Channels | 16 Isolated Inputs
Communication | Foundation Fieldbus H1
Update Rate | 50 ms per Channel
Power Consumption | 1.8W @ 24 VDC
Isolation | 1500 VAC Channel-to-Bus
Certifications | SIL 2, ATEX Zone 2
Operating Temp | -40°C to +70°C
Warranty | 1 Year Replacement

Add to quote
Category:

Description

HONG KONG SAUL ELECTRICAL LIMITED, as a Schneider Electric Certified Partner, delivers mission-critical process control components. With 20+ years of expertise in distributed control systems, we provide lifecycle support for Foxboro I/A Series installations worldwide.

Technical Specifications

Product Model        | P0926GV FBM231
Manufacturer         | Foxboro (Schneider Electric)
Product Type         | 16-Channel Analog Input Module
Input Signal         | 4-20mA ±0.05% FS
Channels             | 16 Isolated Inputs
Communication       | Foundation Fieldbus H1
Update Rate          | 50 ms per Channel
Power Consumption   | 1.8W @ 24 VDC
Isolation           | 1500 VAC Channel-to-Bus
Certifications       | SIL 2, ATEX Zone 2
Operating Temp       | -40°C to +70°C
Warranty             | 1 Year Replacement

Key Features and Advantages

The P0926GV FBM231 features patented signal conditioning technology that rejects 120dB of common-mode noise, ensuring stable measurements in electrically hostile environments. Its dual redundant fieldbus interfaces maintain continuous communication during network disruptions. The module’s hot-swappable design allows replacement without process interruption, while LED per-channel diagnostics enable rapid fault localization. Pre-loaded characterization curves automatically compensate for thermocouple nonlinearities in temperature monitoring applications.

Application Areas

Critical for refinery distillation column control, the P0926GV FBM231 precisely monitors tray temperatures and pressure differentials. Pharmaceutical batch reactors utilize its SIL 2-rated inputs for critical safety interlocks. In LNG liquefaction plants, the module’s -40°C operational capability ensures reliable flow measurement in cryogenic environments. The Foundation Fieldbus integration enables predictive maintenance through asset management systems like AMS Device Manager.

Related Products

FBM242 (32-Channel Digital Input Module)
P0916YQ FBM234 (8-Channel RTD Input)
P0400SV (Redundant Fieldbus Power Supply)
CP40 (Control Processor for I/A Series)
FBM247 (HART-Enabled Analog Output Module)

Installation & Maintenance

Installation preparation: Verify fieldbus segment loading before integrating the P0926GV FBM231 into existing networks. Use certified FISCO barriers for Zone 1 installations. Maintenance recommendation: Our Foxboro-certified engineers provide WhatsApp-based calibration support using Fluke 725EX intrinsically safe calibrators. Perform biennial isolation resistance tests per IEC 61010-1 standards.

Product Assurance

Each P0926GV FBM231 undergoes 72-hour burn-in testing with full loop calibration records. Our Critical Process Support Program guarantees 4-hour emergency response for operational disruptions. Legacy system upgrades include configuration migration with preserved tag databases and alarm setpoints.
