Description
Manufacturer GE General Electric
Series Mark V
Part Number DS200DCFBG1BLC
Product Type Power Supply Board
Instruction Manual GEI-100028
The DS200DCFBG1BLC is a power supply board designed by General Electric for the Mark V series of option
al and replacement boards. Members of this series are cross compatible with a number of GE brand exciters an
d drives. Drives from the DC2000, AC2000, CB2000, ME2000, and FC2000 can all accept this power board. Th
d AC inputs to this board can rate from 38 to 115 VAC. Frequencies accompanying this VAC can range from 0 to 50
0 kHz, depending on the strength of the inputted voltage.
DS200DCFBG1BLC contains a number of intricate circuit systems designed to power a majority of the drive. The
card includes both an AC and DC monitoring circuit, the control level supply circuit, a motor field power circuit, and
a driver circuit. Users can configure the twelve jumpers and seven DIP switches on the card to meet any external r
equirements. Board status is communicated to the user via the onboard indicators. Two LED and one neon indicato
rs are built into the card, providing users with important diagnostic and status information. Three of the board’s fuses a
re protected, ensure that interruptions or surges will not disrupt the currents. Be sure to monitor voltage levels periodi
cally using the five test points integrated into the board.
Following provided installation parameters from both DS200DCFBG1BLC and the drive is imperative. These guidelines will ensure that the board and its installed system operates as intended. For a wiring and installation guide, please refer to the series manual as well as the device datasheet. Technical support for all boards in the Mark V series was originally provided by the manufacturer, General Electric.
