Description
Technical Specifications
| Product Model | **GE IS200TDBSH1A** |
| Manufacturer | General Electric (GE) |
| Product Type | Digital Signal Terminal Board (Mark VIe Turbine Control System) |
| Input Voltage | 24 VDC (Isolated) |
| Channels | 32 digital I/O points (Configurable as Sink/Source) |
| Communication | Ethernet/IP, ControlNet, Mark VIe Peer-to-Peer |
| Isolation | 1500 V channel-to-bus, 500 V channel-to-channel |
| Response Time | <1 ms (State Change Detection) |
| Operating Temperature | -40°C to 70°C (Industrial Harsh Environment) |
| Certifications | UL 508, IEC 61131-2, CE, RoHS |
IS200TDBTH6ABC
Key Features & Advantages
The **GE IS200TDBSH1A** is a high-density digital I/O terminal board designed for GE’s Mark VIe turbine control systems. It provides configurable sinking/sourcing channels for interfacing with limit switches, solenoid valves, and status indicators. The board supports hardware filtering (debounce) for noisy industrial signals and includes surge suppression for inductive loads. Redundant Ethernet ports ensure continuous communication with the controller during network reconfiguration.
Integrated diagnostics detect stuck-at faults, wire breaks, and overcurrent conditions. GE’s ToolboxST software enables logic pre-configuration for fast commissioning, including safety interlock programming. The terminal board’s conformal coating protects against moisture and chemical exposure in offshore or coastal installations.
Applications
Critical for **gas turbine sequencing** (start/stop permissives, flame detection). Used in **hydroelectric plants** for gate position limit switches and lubrication system monitoring. **Compressor stations** leverage its fast response for emergency shutdown (ESD) logic. Also deployed in **wind turbine control cabinets** for pitch system feedback and brake status signals.
Related Products
**IS200TBCIH1C**: Analog Terminal Board.
**DS200TCEAG1ADC**: Excitation Control Card.
**IC693MDL645**: Digital Input Module.
**IS215UCVEH2AE**: Ethernet Switch Module.
**EX2100e Excitation System**.
Installation & Maintenance
**Installation**: Mount in a Mark VIe cabinet using DIN rail slots. Use 18-22 AWG shielded cables for noise immunity; separate AC/DC wiring per NEC Class 1/2 guidelines. Configure I/O mapping via ToolboxST’s HMI interface. **Testing**: Validate ESD logic with simulated fault conditions using Omicron CMC 256. **Maintenance**: Clean terminals annually with contact cleaner; check surge suppressors for wear. Update firmware during turbine outages via GE’s Proficy Machine Edition.
Product Assurance
The IS200TDBSH1A undergoes 50g shock and 5g vibration testing per IEC 60068-2. Rated for 1,000,++ contact cycles on each channel. Includes a 3-year warranty with 15-year lifecycle support for legacy Mark VIe systems. Complies with API 614 lubrication standards and ISO 13849 PL-e safety requirements. GE’s Global Support offers 24/7 troubleshooting and legacy system upgrades (e.g., Mark V to Mark VIe).
