MVME172-263/260 SCSI & Ethernet Interface

Description

Before you power up the MVME172LX system, be sure that the following
conditions exist:
1. Jumpers and/or configuration switches on the MVME172LX VME
Embedded Controller and associated equipment are set as required
for your particular application.
2. The MVME172LX board is installed and cabled up as appropriate
for your particular chassis or system, as outlined in Chapter 1.
3. The terminal that you plan to use as the system console is connected
to the console port (serial port 1) on the MVME172LX module.
4. The terminal is set up as follows:
– Eight bits per character
– One stop bit per character
– Parity disabled (no parity protection)
– Baud rate 9600 baud (the default baud rate of many serial ports
at power-up)
5. Any other device that you wish to use, such as a host computer
system and/or peripheral equipment, is cabled to the appropriate
connectors.
After you complete the checks listed above, you are ready to power up the
system.

MVME172-263/260 SCSI & Ethernet Interface

MVME172-263/260 SCSI & Ethernet Interface
