VMIACC-5595-208 350-805595-208N 2 Gb/s Reflective Memory Hub Assembly
Product Description
https://acoutronic.se/pdf/embedded_systems/GE_Datasheet_vmiacc5565.pdf
- Provides up to Eight Ports Using Small Form Factor Pluggable Transceivers
- Automatically Bypasses Defective or Disconnected Nodes
- Each Port Regenerates the Serial Optical Signal
- Configurable for Cables up to 10 km in Length
The GE Fanuc / VMIC VMIACC-5595 Gb/s Reflective Memory Hub Assembly is a managed hub designed to operate with the GE Fanuc / VMIC 5565 family of Reflective Memory real-time network products. The Reflective Memory hub can automatically bypass ports when it detects a loss of signal or the loss of valid synchronization patterns, allowing the other nodes in the network to remain operational. Since the optical ports are implemented with small form factor pluggable (SFP) transceivers, only the required ports need to be populated. The VMIACC-5595 SFP transceivers can be a combination of either multimode (short distance) or single-mote (long-distance) transceivers.
Product parameter
• Provides up to eight ports using small form factor pluggable (SFP) transceivers
• Hub assemblies can be cascaded with a maximum of 256 nodes
• Automatically bypasses defective or disconnected nodes in a fiber-optic network
• Automatic bypass can be optionally controlled by the loss of signal or by the loss of sync pattern
• Each port regenerates the serial optical signal, eliminating link losses and reducing jitter
• Configurable for use with cables up to 10km in length
• 10BaseT Ethernet TCP/IP port for remote access and control
• RS232 port for local access and control
• Optional 19-inch 1U rack mount or desktop enclosure
• Internal universal power supply
• Dark on Dark option turns off the board’s transmitter if the receiver does not detect a signal (available for firmware versions 02.00 and later)
Application field
This feature permits a cost saving in small networks as well as system optimization. For larger networks, several VMIACC-5595 assemblies can be cascaded, permitting a managed hub aray with up to 256 nodes. Each port regenerates the serial optical signal, eliminating the problems with insertion losses and cable attenuation. Signal regeneration also reduces jitter. The RS232 port gives the ability to monitor and control the Reflective Memory network through a simple PC serial port. The Ethernet port feature allows the user to monitor and control the hub from great distances through a local area network (LAN) or via a Web browser
The VMIACC-5595 can be configured as a 19-inch 1U rack-mountable enclosure or as a desktop enclosure. The universal power supply permits operation with nearly any international power standard.
The VMIACC-5595 automatically bypasses ports when the absence of valid synchronization patterns is detected. Three LEDs, adjacent to each port, provide a visual indication of the port status. Additional status indications and modes of operation are available through either the serial port or the Ethernet port.
Status information includes the detection of installed transceivers, the detection of signal (light), the detection of valid synchronization patterns, and the port operation speed (2Gb/s). Control registers allow the channel bypass to be based on the absence of a single valid synchronization pattern or multiple synchronization patterns. A bypass can also be based simply on the loss of a signal (light). In addition, each port can be manually forced either active or bypassed regardless of the status indicators.
