Description
Product details:
resistive load or inductive load up to 500 mA (12 W),
lamp connection up to 4 W,
with integrated safety shutdown, with safe isolation,
no output signal with break of the L- supply
requirement class AK 1 … 6
The module is automatically tested during operation. The main test routines are:
– Reading back of the output signals. The operating point of the 0 signal
read back is ≤ 6.5 V. Up to this value the level of the 0 signal may arise
in case of a fault and this will not be detected
– Switching capability of test signal and cross-talking (walking-bit test).
Outputs 500 mA, k short circuit proof
Internal voltage drop max. 2 V at 500 mA load
Admissible line resistance (in + out) max. 11 Ohm
Undervoltage tripping at ≤ 16 V
Operating point for
short circuit current 0.75 … 1.5 A
Outp. leakage current max. 350 µA
Output voltage if output is reset max. 1,5 V
Duration of the test signal max. 200 µs
Space requirement 4 TE
Operating data 5 V DC: 110 mA
24 V DC: 180 mA in add. load
Central module F 8650X:
TUV certification, safety level SIL3/AK6. Applicable to H51q system. Two RS485 ports with two cpus in 1OO2 security mode.
Central module F 8652X:
TUV certification, safety level SIL3/AK6. Applicable to the H41q system. Two RS485 ports with two cpus in 1OO2 security mode.
Ethernet communication module F 8627X:
TUV certification, safety level SIL3/AK6. Applicable to H51q and 41q systems. One Ethernet interface to form a secure Ethernet with another F 8627X.
Ethernet communication module F 8621A:
Applicable to H51q and 41q systems. Two RS485 ports for networking with another F 8621A.
Power module F 7126:
Applicable to H51q system. System 5VDC power module.
Power module F 7130A:
Applicable to the H41q system. System 5VDC power module.
Power module F 7131:
Applicable to H51q system. System power monitoring module.
Analog input module F 6217:
TUV certification, safety level SIL3/AK6. Channels are securely isolated from each other, and signals are isolated from the site. (in line with IEC61000 standard), 8 points per card, 4~20mA DC input. The card can supply power to the field instrument.
Switch input module F 3236:
Certified by TUV, safety level SIL3/AK6, with diagnostic function. Channels are securely isolated from each other, and signals are isolated from the field (in accordance with IEC61000 standards). Each card has 16 points. The digital input module (DI) is passive.
Switch output module F 3330:
Certified by TUV, safety level SIL3/AK6, with diagnostic function. Safe isolation between channel and channel, signal and field isolation (in line with IEC61000 standards), 8 points per card, the maximum load capacity of each point is 0.5A, DO signal for active signal output. Each DO channel can be configured with external relays.
Recommended model:
PFSK164 3BSE021180R1 ABB Circuit board card |
IS220PAICH2A 336A4940CSP11 GE analog input/output module |
IC698CRE030-EE GE Pentium-M redundancy CPU |
IC698PSA100 GE power supply module |
IC698CRE040-HN GE Processor module |
FC-QPP-0002 HONEYWELL Quad Processor |
IC695PSA040 GE power supply |
DSBC176 3BSE019216R1 ABB Bus Extender Board |
DVSC-TT-14C-09 DOOSAN Driver module |
DS200TCEAG1BNE DS215TCEAG1BZZ01A GE Emergency Over Speed Board |
DS200TCEAG1ACB GE Processor module |
DO820 3BSE008514R1 ABB Digital Output |
CI840A 3BSE041882R1 ABB Profibus DP-V1 Communication Interface |
DSAO120A 3BSE018293R1 ABB Analog Output Board |
AI810 3BSE008516R1 ABB Analog Input |
