51405038-475 CC-PAIX02 Analog Input Module​

Description

​​Honeywell 51405038-475 (CC-PAIX02) Analog Input Module​​

https://example.com/image-cc-paix02.jpg ​​Product Overview​​ The Honeywell ​​51405038-475​​, commercially designated as the ​​CC-PAIX02​​, is an 8-Channel Analog Input Module for the Experion® PKS (Process Knowledge System) platform. This module serves as a critical interface between analog field instruments and the digital control system, providing high-accuracy signal conditioning and conversion for a wide range of process variables. Designed for high reliability and precision, the CC-PAIX02 accepts standard analog signals from transmitters and sensors, converting them into digital values for monitoring and control within the Experion PKS environment. The module features advanced diagnostics and flexible configuration options, making it suitable for critical process applications across various industries.

​​Key Features​​

• ​​High-Density Design:​​ Provides 8 isolated analog input channels in a single module slot, optimizing control cabinet space
• ​​Multi-Signal Support:​​ Configurable per channel for various input types:

• 4-20 mA current input (with HART support)
• Thermocouple (T/C) inputs (J, K, T, E, R, S, B, N types)
• RTD inputs (2-wire, 3-wire, or 4-wire PT100, PT1000, Cu10, Ni120)
• Voltage inputs (0-5V, 0-10V, ±5V, ±10V)
  • ​​HART Protocol Support:​​ Enables digital communication with HART-enabled field devices for configuration, calibration, and diagnostics without interrupting the 4-20 mA signal
  • ​​Advanced Diagnostics:​​ Comprehensive self-diagnostics including channel fault detection, open circuit detection, and out-of-range alarms
  • ​​Hot-Swappable:​​ Supports online insertion and removal for maintenance without process shutdown
  • ​​High Accuracy:​​ Exceptional measurement precision suitable for critical process control applications
  • ​​LED Status Indicators:​​ Per-channel and module-level status LEDs for quick visual health monitoring

​​Technical Specifications​​

​​Typical Applications​​

• ​​Process Monitoring:​​ Pressure, temperature, flow, and level measurements from field transmitters
• ​​Temperature Sensing:​​ Direct connection to thermocouples and RTDs for temperature monitoring
• ​​HART Device Integration:​​ Smart transmitter configuration and device diagnostics
• ​​Batch Processes:​​ Precise measurement and control in pharmaceutical and chemical applications
• ​​Safety Systems:​​ Critical process variable monitoring for safety instrumented systems

​​Configuration and Installation​​

• ​​Engineering Tool:​​ Configured using Honeywell ​​Control Builder​​ software
• ​​Mounting:​​ Installs in Experion PKS Series A or C I/O modules
• ​​Wiring:​​ Front-accessible terminal blocks for easy field wiring
• ​​Configuration:​​ Per-channel signal type selection and scaling parameters
• ​​Diagnostics:​​ Comprehensive health monitoring and alarm configuration

​​Ordering Information​​

• ​​Complete Assembly:​​ 51405038-475 (includes CC-PAIX02 module)
• ​​Commercial Code:​​ CC-PAIX02
• ​​Spare Parts:​​ Terminal blocks, labeling kits available separately

​​Disclaimer​​ This information is for reference purposes only. Specifications are subject to change by the manufacturer. For complete technical details, installation instructions, and safety information, consult the official ​​Honeywell Experion PKS CC-PAIX02 Product Data Sheet​​. Always verify compatibility with your specific system configuration and follow all applicable safety procedures during installation and maintenance.
