CC-PDIL01 51405040-175 digital input module
Product Description
Product Overview:
The CC-PDIL01 is a Low Voltage Digital Input (24 volts DC) module for receiving and processing digital signals from external sensors.
It provides 32 channels for connecting various sensors or devices that require 24VDC power.
Electrical parameters:
Rated voltage: 24VDC
Logic 1:15 VDC or 2.5mA (minimum)
Logic 0:5 VDC or 1mA (Max)
Input current: From the load voltage L+(no load) Max 90mA, from the backplane bus 5VDC Max 130mA
Input type:
Missing input/source input type (IEC Class I missing input) modules that support positive or negative logic inputs.
Isolation and protection:
Photoelectric isolation (field power supply and logic power supply) ensures electrical isolation between the input signal and the internal logic circuit.
Isolation voltage up to 500VAC and duration of 1 minute provide additional electrical safety protection.
Working environment:
The allowable operating temperature range is -25°C to +55°C (the specific range may vary by model).
Cable length: up to 500m with shielding, up to 300m without shielding.
Installation and connection:
DIN rail mounting is usually used for easy integration in the control cabinet.
Connect to external sensors or devices via standard terminals.
Compatibility:
Can be used with a variety of industrial automation systems and controllers, such as PLC, DCS, etc.
Supports a variety of communication protocols to facilitate data exchange with other systems or devices.
Application field:
CC-PDIL01 is widely used in CNC machinery, metallurgy, petroleum and natural gas, petrochemical, chemical, paper printing, textile printing and dyeing, machinery, electronic manufacturing, plastic machinery, electric power, water conservancy, water treatment/environmental protection, municipal engineering, boiler heating, energy, power transmission and distribution and other industries.
Product parameter
CC-PDIL01 parameters mainly include the following aspects:
Product Overview:
Product type: Digital input 24 VDCIOM
Block name: DI-24
Rated voltage: 24VDC
Number of channels and input type:
Number of channels: 32
Input type: Missing input/source input type (IEC Class I missing input)
Logic level:
Logic 1:15 VDC or 2.5mA (minimum)
Logic 0:5 VDC or 1mA (Max)
Input current:
Load voltage L+(no load) Max. : 90mA
From the backplane bus 5VDC maximum: 130mA
Isolation and protection:
Photoelectric isolation (field power and logic power)
Isolation voltage: 500VAC, 1 min
Working environment:
Allowable operating temperature: 55°C
Cable length: 500m with shielding, 300m without shielding
Other features:
Suitable for industrial automation and control systems
Widely used in many industries, such as CNC machinery, metallurgy, oil and gas, petrochemical, chemical and so on
Application field
CC-PDIL01 has a wide range of applications, including but not limited to the following industries:
CNC machinery: In CNC machine tools, machining centers and other equipment, CC-PDIL01 can be used to receive and process digital signals from various sensors and equipment to achieve real-time monitoring and control of the running state of the machine tool.
Metallurgical industry: In the metallurgical production process, CC-PDIL01 can be used to monitor and control the operating status of smelting furnaces, rolling mills and other equipment to ensure the stability and safety of the production process.
Oil and gas, petrochemical, chemical industry: In these industries, CC-PDIL01 can be applied to oil and gas field exploitation, refining, chemical production and other links, for monitoring and control of various process parameters, such as temperature, pressure, flow, etc.
Paper printing, textile printing and dyeing industry: In the process of paper printing and textile printing and dyeing, CC-PDIL01 can be used to monitor and control the operating state of the equipment, such as the tension of the paper, the speed of the printing press, the weaving process of the textile machine.
Electronic manufacturing industry: In the electronic manufacturing process, CC-PDIL01 can be used to monitor and control various production equipment, such as welding machines, testing machines, etc., to ensure the quality and production efficiency of electronic products.
Power, water conservancy, water treatment/environmental protection industry: In the power, water conservancy, water treatment/environmental protection and other industries, CC-PDIL01 can be used to monitor and control various equipment and systems, such as generator sets, water treatment equipment, environmental protection equipment, etc., to ensure the normal operation of these equipment and systems and energy saving and emission reduction.
Municipal engineering, boiler heating, energy, power transmission and distribution industry: In municipal engineering, boiler heating, energy, power transmission and distribution and other industries, CC-PDIL01 can also play an important role in monitoring and controlling various equipment and systems to ensure the normal operation of urban infrastructure and efficient use of energy.
In short, CC-PDIL01, as a digital input module, has a wide range of application prospects in the field of industrial automation and control systems.
