Description
EG1033AA01 EG Flame Amplifiere (LG Series)
- Manufacturer : Honeywell
- EG Amplifier for LG series
- EG1033AA01
- Honeywell Gas Turbine flame monitoring systems
- The Honeywell LG/EG flame monitoring system detects the UV radiation emitted by a hydrocarbon flame and produces an output signal to indicate a
- Flame or noflame condition.
- This system has delivered proven performance on General Electric (and GE licensee) gas turbines for more than 35 years.
- Geiger Mueller-type sensor phototube.
- Detects UV radiation in the 180..260nm range of the spectrum. Solar blind and tolerant to black body radiation.
- Two-year shelf-life, 10000h MTBF with over one billion (109) operating hours.
- Gas Turbines for power genaration and compressors
EG1033AA01
- Temperature range : -40…176C
- Hardware outputs : For EG1033 amplifier modules only
- EG1033AA : Transistor open collector
- EG1033AB and EG1033AC : Relay contacts (SPDT)
- Features : High sensitivity with fast Flame Present Response Time (0.1 sec typical)
- Flame Loss Response Time: 0.2 sec max.
- Amplifiers support multiple voltage requirements : 28 Vdc, 20-35 Vdc and 115 Vac.
- Operating distances up to 330m (1000ft), sensor to amplifier.
- Qualified component on General Electric turbines.
- Available with European Directive CE mark for EMC 89/336/EEC, LVD 73/23/EEC and ATEX Explosive Atmosphere 94/9/EC
- (EEx d IIA T3 or EEX d IIC T3, Zone 1 and 2).
- Available with Factory Mutual approval for explosive atmospheres (Class I, Div 1 and 2, Groups B, C and D).
- Amplifier modules
- Model : Transistor open collector output
- Supply voltage : 24..28 Vdc
- Approvals : No
- Shipping Weight : 15 Kg
