FC-TSDI-16UNI digital input module
Product Description
FC-TSDI-16UNI Product description
I. Product overview
The FC-TSDI-16UNI is a digital input module manufactured by Honeywell and designed for industrial control systems. It can receive digital signals from various sensors and convert them into a form that can be processed by a programmable logic controller (PLC), thus achieving precise control of industrial production processes.
Two, the main characteristics
High accuracy and reliability: FC-TSDI-16UNI stands out among similar products for its high accuracy and high reliability, ensuring the accuracy and stability of signal transmission.
Easy installation and maintenance: The module design is simple, easy to install and configure, but also simplifies the maintenance process, reducing operating costs.
Safety features: The FC-TSDI-16UNI also features a secure digital input field terminator component. When the system is fault-free, the inputs are defined as safety-relevant and the inputs are red on the online FLD diagram. If the system detects a hardware failure, a series of security measures are triggered.
Product parameter
- Manufacturer : Honeywell
- Product No. : FC-TSDI-16UNI
- Product type : Safety Manager System Module
- Approvals: CE, TUV, UL, CSA, FM
- Number of channels: 16 (2 groups of 8)
- Maximum voltage:
- 50 Vdc – IEC 61010-1 (1990), over voltage category 3
- 150 Vdc – IEC 61010-1 (1990), over voltage category 2
- Module dimensions: 90 × 70 × 60 mm (L × W × H)
- DIN EN rails: TS32 / TS35 × 7.5
- Used rail length: 91 mm (3.58 in)
- Fuse Rating: 250 mAT (slow-acting)
- Fuse Dimensions: 5 × 20 mm (0.2 × 0.79 in)
- Screw terminals:
- Max. wire diameter 2.5 mm² (AWG 14)
- Strip length 7 mm (0.28 in)
- Tightening torque 0.5 Nm (0.37 ft.-lb.)
- Shipping weight : 2 Kg
Application field
FC-TSDI-16UNI modules are widely used in various industrial control fields requiring high-precision digital signal processing, such as petrochemical, power energy, water treatment, food and medicine. In these fields, it is used in conjunction with other industrial automation equipment and systems to achieve automation and intelligent control of the production process.
5. Features of secure digital input field terminating components
When the system is fault-free, the inputs are defined as safety-relevant, and the inputs on the online FLD diagram are red.
If the system detects a hardware failure, a series of safety measures will be triggered, such as DBM flashing, Input-Failure system marker turning 0, application value turning low (0), etc.
Six, precautions
When using the FC-TSDI-16UNI module, ensure that it is installed and configured according to the product instructions.
If you have any technical problems or questions, please contact the product supplier or professional technicians for help.
Please pay attention to the maintenance and maintenance of the product to ensure that it is in good working condition.
