SC-PCMX01 51307195-175 HC900 Hybrid control

Product details:

SC-PCMX01 51307195-175 HC900 is an open control system for small and medium-sized process users and equipment integrated control launched by Honeywell in April 2002. The system is composed of advanced integrated controller HC900 with refined design and high performance engineer/operator stations connected by independent or open Ethernet network to form a complete set of distributed control system and can really meet all the industrial industry from simple to complex control application requirements. HC is the acronym of Hybrid Control, which means that the system integrates multiple control strategies such as continuous control, logical control, and sequential control. With decentralized modular structure and advanced control functions, HC900 integrates users’ continuous and discrete control requirements for process equipment, adopts fully open communication standards, and uses the web-based real-time monitoring software PlantScape Vista developed by Honeywell or third-party software as the system application management. Advanced integrated controller HC900 with refined design as the equipment control layer, at the price level close to PLC, to provide users with cost-effective distributed control system.

Communication with the upper computer through 100M Ethernet interface, using the open MODBUS/TCP protocol, so the upper computer software

PlantScape Vista, manufactured by Honeywell, is available, or third-party software that supports the agreement is available
The port supports a maximum of five concurrent connections.

It realizes point-to-point communication through Ethernet, that is, data exchange can be realized between controllers.
RS-232 serial port supports local and remote dialing for communication configuration/diagnosis;
The connection to the operator disk is achieved through the RS-485 interface and using specific protocols.

The hardware of the SC-PCMX01 control system mainly consists of the upper management/monitoring/programming computer, controller and I/O modules and operations
The crew panel consists of three parts, among which the local operator panel is optional. It has a 10.4 inch color LCD screen and 100 prefabricated monitor pictures
Face, with data recording/trend display, is the best local operator interface.
A. Communication interface
