Product details：

Manufacturer : ICS Triplex
Product No. : T8311
Product type : Trusted TMR Expander Interface
Voltage Range : 20 to 32V dc
Heat Dissipation : 40W
Use with Chassis : T8300
Maximum Load : 40W
Module Clocks : 50MHz
Expander Bus Data Rate : 250Mbps
Manufacturer : ICS Triplex
I/O Interface : Expander Chassis backplane
Operating Temperature : -5°C to 60ºC (13°F to 140°F)
Non-operating Temperature : -25°C to 70ºC (-25°F to 158°F)
Operating Humidity : 5 to 95% RH
Dimensions (LxWxH) : 30.3 cm x 3.1 cm x 26.6cm

Peer network control board Configures and controls the network for data transmission between peer I/O boards. The board must be defined before the I/O board.
There are eight different peer I/O boards (input and output, digital and analog, 16 and 128 channels). Each input board has an output board with the same type and number of channels. In order for the I/O boards to communicate with each other, they must share the same network, peer, and data identity. The combination of these three identities should be considered a global data identifier that must be uniquely defined for each I/O board pair throughout the peer network.
Think of it as routing multi-core cables between systems. Each multi-core cable is placed in a tray (network). Different multi-core cables (subnets) can be routed in a single tray. Each controller on the network has a unique identifier (peer ID). The wires at each end must be matched to similar devices (analog/digital) with the same number of channels (16 or 128).
