Description
Product Name: 1FK7101-5AY71-1SY3-ZS77
Manufacturer: KUKA AG
Product Series: 1FK7 Servomotor Series
Certification: CE, UL, ISO 13849-1
Product Overview
The KUKA 1FK7101-5AY71-1SY3-ZS77 is a high-performance synchronous servomotor engineered for precision motion control in industrial automation applications. Designed for seamless integration with KUKA robotic systems and CNC machinery, it delivers exceptional torque density, dynamic response, and operational reliability.
Key Features
- High Torque Density
- Rated Torque: 15 Nm (peak torque up to 45 Nm).
- Compact Design: Optimized for space-constrained installations.
-
- Dynamic Performance
- Speed Range: 0–3,000 rpm (smooth operation under load).
- Low Inertia Rotor: Enables rapid acceleration/deceleration.
-
- Precision Feedback
- Integrated 24-bit multiturn absolute encoder (EnDat 2.2 interface).
- Positioning accuracy: ±0.001°.
-
- Robust Construction
- IP67 Protection Rating: Resistant to dust, moisture, and coolants.
Housing Material: Anodized aluminum with stainless steel shaft.
-
- Thermal Efficiency
- Class F Insulation: Supports continuous operation at 40°C ambient temperature.
Optional forced-air or water cooling for high-duty cycles.
Technical Specifications
| Parameter | Specification |
| Rated Voltage | 400 VAC (3-phase) |
| Rated Current | 4.8 A |
| Power Rating | 2.5 kW |
| Weight | 12.5 kg |
| Shaft Type | Keyway shaft with sealing ring |
| Connector Type | M23 circular connector (IP67) |
| Certifications | CE, UL, ISO 13849-1, RoHS |
Applications
Industrial robotics (e.g., KUKA KR Quantec series).
CNC machine tools (milling, grinding, spinning).
Packaging and material handling systems.
Semiconductor manufacturing equipment.
Integration & Compatibility
Drives: Compatible with KUKA KSD series and industry-standard servo drives.
Control Systems: Supports KUKA System Software 8.0+ and PROFINET/ETHERCAT protocols.
Feedback System: EnDat 2.2 for real-time position/speed feedback.
Benefits
Energy Efficiency: Regenerative braking reduces power consumption.
Low Maintenance: Sealed bearings and brushless design.
Safety Compliance: Meets ISO 13849-1 PL e (Category 3) for functional safety.
