3350-MBP Micro-Beta Pattern Portable Air Particle Counter​

Parameter
Specification
​​Model​​
3350-MBP
​​Flow Rate​​
28.3 LPM (1.0 CFM) ±5%
​​Particle Sizes​​
0.3, 0.5, 1.0, 3.0, 5.0, 10.0 µm (Standard)
​​Coincidence Loss​​
<5% at 1,000,000 particles/ft³ (via MBP technology)
​​Counting Efficiency​​
50% at 0.3µm, 100% at 0.45µm (as per JIS)
​​Zero Count​​
<1 count per 5-minute interval (as per JIS B 9921)
​​Display​​
7-inch full-color touchscreen LCD
​​Data Logging​​
Internal memory for >1,000,000 sample records
​​Output/Communication​​
USB Port, Ethernet (Wi-Fi optional)
​​Power Supply​​
Li-ion Battery (≥6 hours operation), AC Adapter
​​Dimensions & Weight​​
Approximately 270 x 155 x 115 mm (10.6″ x 6.1″ x 4.5″), ~2.8 kg (6.2 lbs)
​​Standards Compliance​​
ISO 14644-1, EU GMP Annex 1, JIS B 9921, FDA 21 CFR Part 11 (with compliant software)
Add to quote
Category:

Description

3350-MBP | Micro-Beta Pattern Portable Air Particle Counter​​

​​Product Code:​​ 3350-MBP
The 3350-MBP is a state-of-the-art, portable air particle counter designed for critical environmental monitoring in cleanrooms, isolators, and controlled environments. Its innovative ​​Micro-Beta Pattern (MBP)​​ detection technology provides superior coincidence loss control, ensuring high counting accuracy even at high particle concentrations. Engineered for compliance and efficiency, it is the ideal tool for certification, monitoring, and validation processes in industries where air purity is paramount.
![Image of the 3350-MBP Portable Air Particle Counter]

​​Key Features​​

  • ​​Micro-Beta Pattern (MBP) Sensor:​​ Patented sensor technology minimizes coincidence loss, delivering exceptional accuracy for particle counts across all channels, especially in demanding Grade A/B (ISO 5) environments.
  • ​​Multi-Channel Sizing:​​ Simultaneously counts and reports up to 6 particle sizes, typically configured as 0.3, 0.5, 1.0, 3.0, 5.0, and 10.0 µm, aligning with ISO 14644-1 and EU GMP Annex 1 standards.
  • ​​High Flow Rate:​​ Maintains a constant flow rate of ​​1.0 CFM (28.3 LPM)​​, as required by international standards for cleanroom classification.
  • ​​Intuitive User Interface:​​ Features a vibrant color touchscreen for easy navigation, real-time data visualization, and quick setup of complex sampling plans.
  • ​​Comprehensive Data Management:​​ Includes a powerful internal data logger with a battery backup, storing over 1,000,000 records. Seamless data export via USB or Ethernet.
  • ​​Compliance Ready:​​ Pre-loaded with standard operating procedures (SOPs) for sampling locations, volume, and counts per cubic meter/foot to meet ISO 14644-1, EU GMP Annex 1, and FDA requirements.
  • ​​Robust & Portable:​​ Designed with a durable housing and a long-lasting battery for full-shift mobility within your facility.

3350-MBP

​​Technical Specifications​​

Parameter
Specification
​​Model​​
3350-MBP
​​Flow Rate​​
28.3 LPM (1.0 CFM) ±5%
​​Particle Sizes​​
0.3, 0.5, 1.0, 3.0, 5.0, 10.0 µm (Standard)
​​Coincidence Loss​​
<5% at 1,000,000 particles/ft³ (via MBP technology)
​​Counting Efficiency​​
50% at 0.3µm, 100% at 0.45µm (as per JIS)
​​Zero Count​​
<1 count per 5-minute interval (as per JIS B 9921)
​​Display​​
7-inch full-color touchscreen LCD
​​Data Logging​​
Internal memory for >1,000,000 sample records
​​Output/Communication​​
USB Port, Ethernet (Wi-Fi optional)
​​Power Supply​​
Li-ion Battery (≥6 hours operation), AC Adapter
​​Dimensions & Weight​​
Approximately 270 x 155 x 115 mm (10.6″ x 6.1″ x 4.5″), ~2.8 kg (6.2 lbs)
​​Standards Compliance​​
ISO 14644-1, EU GMP Annex 1, JIS B 9921, FDA 21 CFR Part 11 (with compliant software)

​​Applications​​

The 3350-MBP is essential for monitoring and certification in critical environments, including:
  • ​​Pharmaceutical & Biotechnology Cleanrooms​​
  • ​​Sterile Manufacturing & Fill-Finish Areas​​
  • ​​Medical Device Manufacturing​​
  • ​​Hospital Compounding Aseptic Isolators (C-PECs)​​
  • ​​Electronics and Semiconductor Manufacturing​​
  • ​​Research Laboratories​​

​​Benefits​​

  • ​​Unmatched Accuracy:​​ MBP technology ensures reliable data for critical decision-making, reducing the risk of false passes/failures.
  • ​​Regulatory Confidence:​​ Simplifies compliance with global GMP and ISO standards, ready for audits.
  • ​​Improved Efficiency:​​ Streamlines environmental monitoring programs with easy-to-use features and robust data integrity.
  • ​​Enhanced Productivity:​​ Portable, long-lasting design enables comprehensive monitoring of multiple locations without interruption.
